MPI™ MAB Series Electric Actuator - 120VAC, Explosion Proof, ATEX Approved
MPI™ MAB Series Electric Actuator - 120VAC, Explosion Proof, ATEX Approved
SKU:VAL-5c3f72
Precision control with MPI™ MAB Series Electric Actuator - 120VAC, explosion-proof design for demanding environments.
Regular price
$399.99
Regular price
Sale price
$399.99
Unit price
per
Initiate Order
MPI™ MAB Series Electric Actuator - 120VAC, Explosion Proof, ATEX Approved
$399.99
Quantity: 1
Claim Your Seller Account
MPI™ MAB Series Electric Actuator - 120VAC, Explosion Proof, ATEX Approved
$399.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The MPI™ MAB Series Electric Actuator is designed for precision control in demanding environments. Operating from -4oF to 158oF, this actuator features a powder-coated aluminum housing for durability. It is CE & CSA approved with a manual override for flexibility. The 3/4" NPT female conduit connection ensures easy installation. This explosion-proof enclosure meets II 2 G, EEx-d IIB T4, IP67, ATEX standards. Complying with NEMA 7 Explosion Proof and IP68 Watertight enclosure ratings, this actuator is ideal for applications in laboratories, pilot plants, control panels, and more.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Dimensions A
5.00 in
Dimensions Actuator Height
11.97 in
Dimensions Actuator Length
11.49 in
Dimensions Actuator Width
10.2 in
Dimensions B
2.50 in
Dimensions C
3.25 in
Dimensions D
1.63 in
Dimensions E
.53 in
Dimensions F
5.00 in
Dimensions No Load Time Openclose
8.5 sec
Dimensions Voltage
120 AC V
Specifications Applications
LaboratoriesPilot PlantsTest StandsWater Blasting Pumping UnitsControl PanelsChemical ResearchHigh Volume Chemical Injection Skids
Specifications Features
Interface with control systems for automated operation and monitoring120 & 220 VAC, 50/60 Hz standard24VDCATEX Flameproof, Explosion Proof options availableCE mark available
