The MPI™ Metal Seat Relief Valve from the MARA Series by Parker is a precision-engineered solution designed to provide reliable venting of gases or liquids in pressure gas systems, cryogenic systems, and petrochemical applications. With set pressures ranging from 3,000 psi to 15,000 psi, this valve ensures safe and efficient operation within a temperature range of -423ºF to 400ºF. Notable features include the ability to handle air, gases, steam, vapor, and liquids, while maintaining accuracy within +/-3% of setpoint. The valve is factory set, maintaining compliance with industrial standards and offering peace of mind to customers.
Product Specifications
Dimensions A
10.62 in
Dimensions Back Pressure Max
500 psi | 34 bar
Dimensions Connection
MPI™ to FNPT
Dimensions Orifice Diameter
.188 in
Dimensions Pressure Rating Max
15000 psi | 1035 bar
Dimensions Pressure Rating Min
10000 psi | 690 bar
Dimensions Repair Kits
R8MARA-15K-2507
Dimensions Size
1/2 x 3/4
Specifications Caution
Parker Relief Valves are preset and factory sealed. Warranty is voided if seal is broken by customer. Maximum system operating pressure should not exceed 90% of relief valve set pressure. Pressures in excess of this value may cause weepage resulting in damage to plug and seat.Care should be taken when locating a relief valve within a piping system to keep the relief valve as far from the pump as possible. Certain pumps create an end-of-stroke spike in pressure that is not detectable by common instrumentation. These spikes could cause premature failure of the relief valve.
