MS21252C Clevis Turnbuckle Clip Locking

MS21252C Clevis Turnbuckle Clip Locking

SKU:MIL-25fd3f

High-strength MS21252C Clevis Turnbuckle Clip Locking for military use. Replaces AN 161. Specifications meet military standards.

Regular price $49.99
Regular price Sale price $49.99
Sale

Initiate Order

MS21252C Clevis Turnbuckle Clip Locking

MS21252C Clevis Turnbuckle Clip Locking

$49.99

Quantity: 1

Claim Your Seller Account

MS21252C Clevis Turnbuckle Clip Locking

MS21252C Clevis Turnbuckle Clip Locking

$49.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The MS21252C Clevis Turnbuckle Clip Locking is a high-strength fastening solution designed for military applications. With a Wire Rope Diameter Reference of 5/32 inches and a Minimum Breaking Strength (MBS) of 3,200 lbs, this turnbuckle ensures secure connections in demanding conditions. Compliant with Military Specification MS21252C, it replaces the outdated AN 161 standard, offering precise Thread UNF-3A measurements and a durable construction that meets stringent military requirements.

Product Specifications

Specifications C 006 000 Diain
.189
Specifications D 002 000 Diain
.250
Specifications F 010 005
.452
Specifications G 010 000
.218
Specifications H
.531
Specifications K Max
.0103
Specifications Mbs Lbs
3,200
Specifications M Max
.2224
Specifications M Min
.2152
Specifications Nsn
N/A
Specifications S Spher Dia
.641
Specifications Thread T Unf 3a
1/4-28
Specifications Wire Rope Dia Ref
5/32
Specifications Y 047
.625
Specifications Z 047
2.734
CAGE
0T9L4
NAICS
332999
PSC
5340
