MSHR-1050-100 Motorized Spring-assisted Hose Reel (MSHR)

Name: MSHR-1050-100 Motorized Spring-assisted Hose Reel (MSHR)
Brand: Plymovent Corp.
SKU: HOS-c87e85
Price: 49.99 USD
Availability: OutOfStock

SKU:HOS-c87e85

N/A

$49.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Motorized Spring-operated Hose Reel (MSHR) combines the benefits of two Plymovent hose reels, SER and MHR. MSHR includes both a recoil motor and spring cassette, making it ideal for facilities with heavy-duty trucks that demand more lifting capacity, due to the weight of the hose and nozzle. With MSHR, the hose will stay in any position until the up or down button is engaged.With the hose elevated, operators can safely use otherequipment in the workshop such as cranes or lifts, while also limiting potential damage to personnel and vehicles.Designed to retract the hose with an electric motor that is assisted by a spring.

Product Specifications

Specifications Applications

The MSHR motorized spring-assist reel can lift an exhaust hose and nozzle. A standard overload relay and circuit breaker protect the mechanism from accidental strain.

Specifications Current

1.8 A | 2.7 A

Specifications Frequency

50/60 Hz | 60 Hz

Specifications Hose Diameter

4 Inch | 100 mm

Specifications Maximum Hose Length

41.0 ft | 12.5 m

Specifications Output

320 W | 390 W

Specifications Phases

Single Phase

Specifications Power Supply

120 V | 230 V

Specifications Rpm

12 | 14

Specifications Weight Without Hose

140 lb | 64 kg

MSHR-1050-100 Motorized Spring-assisted Hose Reel (MSHR)
