Multi-Flex 118 Series Pipe Repair Packers/Carrier
Multi-Flex 118 Series Pipe Repair Packers/Carrier
SKU:PLA-31a8b6
Versatile inflatable pipe repair packers for diameters 5-18 inches, easy to install & remove, ideal for institutional and industrial use.
Regular price
$799.99
Regular price
Sale price
$799.99
Unit price
per
Initiate Order
Multi-Flex 118 Series Pipe Repair Packers/Carrier
$799.99
Quantity: 1
Claim Your Seller Account
Multi-Flex 118 Series Pipe Repair Packers/Carrier
$799.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Multi-Flex 118 Series Pipe Repair Packers/Carrier is a versatile solution for repairing pipelines with diameters ranging from 5 inches to 18 inches. Made from high-strength flexible materials, these inflatable packers offer smooth and even relining without compromising on durability. With the ability to be inflated with air, hot water, or steam, these packers ensure easy installation and removal, making them ideal for swift repairs in institutional and industrial settings. The flow-thru design allows for uninterrupted flow during repairs, while the lightweight construction aids in effortless placement. Ensure reliable pipeline repairs with the Multi-Flex 118 Series.
Product Specifications
Drum Capacity Cable Length Diameter
28.6 mm | 151 m
Drum Capacity Drum Capacity
1-1/8 in | 495 ft
Features Features
Efficient two-stage hydraulic planetary designMultiple disc brake is spring-applied and hydraulically releasedSpring-loaded clutch design disengages for free spoolingAir shift operation
High Speed High Speed Bare Drum Line Pull
65000 lbf | 290 kN
High Speed High Speed Bare Drum Line Speed
32 ft/min | 10 m/min
High Speed High Speed Full Drum Line Pull
31000 lbf | 140 kN
High Speed High Speed Full Drum Line Speed
64 ft/min | 20 m/min
Hydraulic Motor Hydraulic Motor Flow
60 gal/min | 230 L/min
Hydraulic Motor Hydraulic Motor Pressure
2500 lbf/in² | 18 MPa
Low Speed Low Speed Bare Drum Line Pull
130000 lbf | 580 kN
Low Speed Low Speed Bare Drum Line Speed
16 ft/min | 5 m/min
Low Speed Low Speed Full Drum Line Pull
62000 lbf | 280 kN
Low Speed Low Speed Full Drum Line Speed
32 ft/min | 10 m/min
Specifications Gear Ratio
212:1
Specifications Weight
2200 lb | 1000 kg
