Multi-Flexâ¢ 119 Series Point Repair Packers/Carrier

Name: Multi-Flexâ¢ 119 Series Point Repair Packers/Carrier
Brand: WPT Power Corporation
SKU: PLA-25d694
Price: 799.99 USD
Availability: OutOfStock

SKU:PLA-25d694

Versatile, high-strength 20-inch pipeline repair packer with flow-thru design. Easy installation & removal.

$799.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Multi-Flexâ¢ 119 Series 20 Inch Point Repair Packers/Carrier with By-Pass is a versatile solution for pipeline repair and maintenance. Made from high-strength flexible materials, this packer offers smooth and even relining, ensuring a consistent repair diameter. It is lightweight and easy to install and remove, suitable for use with air, hot water, or steam for efficient repairs. The by-pass design allows flow through during operations, enhancing flexibility and convenience. Custom configurations are also available for specific requirements.

Product Specifications

Bare Drum Bare Drum Line Pull

8000 lbf | 36 kN

Bare Drum Bare Drum Line Speed

138 ft/min | 42 m/min

Drum Capacity Cable Length Diameter

13 mm | 105 m

Drum Capacity Drum Capacity

1/2 in | 344 ft

Features Features

Efficient two-stage hydraulic planetary designMultiple disc brake is spring-applied and hydraulically releasedEasily serviced compact designManual override option available

Full Drum Full Drum Line Pull

5600 lbf | 25 kN

Full Drum Full Drum Line Speed

200 ft/min | 60 m/min

Hydraulic Motor Hydraulic Motor Flow

65 gal/min | 246 L/min

Hydraulic Motor Hydraulic Motor Pressure

1400 lbf/inÂ² | 9.7 MPa

Specifications Gear Ratio

59:1

Specifications Weight

415 lb | 188 kg

Multi-Flexâ¢ 119 Series Point Repair Packers/Carrier
