Music Wire Compression Spring - 0.18" OD, 0.036" WD, 1.25" Free Length

Name: Music Wire Compression Spring - 0.18" OD, 0.036" WD, 1.25" Free Length
Brand: Murphy & Read Spring Mfg. Co., Inc.
SKU: COM-35fd28
Price: 5.83 USD
Availability: OutOfStock

SKU:COM-35fd28

Reliable Music Wire Compression Spring - 0.18" OD, 0.036" WD, 1.25" Free Length - Ideal for Various Applications

$5.83

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Meet your compression spring needs with precision and reliability using this Music Wire Compression Spring. With an outside diameter of 0.18 inches, wire diameter of 0.036 inches, and a free length of 1.25 inches, this spring offers a load capacity of 13.12 (MW) and 11.41 (SS), ensuring efficient performance. The composition of music wire enhances durability and resilience, making it ideal for various applications. Additionally, the 22.444 total coils and a spring rate of 39.56 (MW) and 34.4 (SS) further exemplify its high-quality construction and performance standards.

Product Specifications

Specifications Ends

FEG

Specifications Free Length

1.250

Specifications Length L1

0.918

Specifications List Price

5.83 USD

Specifications Load At L1 Mw

13.12

Specifications Load Ss

11.41

Specifications Material

Music Wire

Specifications Outside Diameter

0.18

Specifications Solid Ht

0.808

Specifications Spring Rate Mw

39.56

Specifications Spring Rate Ss

34.4

Specifications Total Coils

22.444

Specifications Type

Compression

Specifications Wire Diameter

0.036

Music Wire Compression Spring - 0.18" OD, 0.036" WD, 1.25" Free Length
