Music Wire Compression Spring - 0.24in OD, 0.04in WD, 1.375in Free Length

Name: Music Wire Compression Spring - 0.24in OD, 0.04in WD, 1.375in Free Length
Brand: Murphy & Read Spring Mfg. Co., Inc.
SKU: COM-a7a97c
Price: 5.83 USD
Availability: OutOfStock

SKU:COM-a7a97c

High-quality Music Wire Compression Spring for precise applications. 0.24in OD, 0.04in WD, 1.375in Free Length.

$5.83

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Music Wire Compression Spring features an outside diameter of 0.24 inches, wire diameter of 0.04 inches, and a free length of 1.375 inches. Designed for precision and durability, this spring provides a load of 12.89 MW and 10.9 SS, with a spring rate of 27.48 MW and 23.57 SS. Its FEG ends ensure secure fitting, while the solid HT construction guarantees reliability. Ideal for a wide range of applications, this compression spring offers consistent performance and quality, meeting stringent industry standards.

Product Specifications

Specifications Ends

FEG

Specifications Free Length

1.375

Specifications Length L1

0.906

Specifications List Price

5.83 USD

Specifications Load At L1 Mw

12.89

Specifications Load Ss

10.9

Specifications Material

Music Wire

Specifications Outside Diameter

0.24

Specifications Solid Ht

0.749

Specifications Spring Rate Mw

27.48

Specifications Spring Rate Ss

23.57

Specifications Total Coils

18.725

Specifications Type

Compression

Specifications Wire Diameter

0.04
