MV001 Song Chuan Middle Voltage Relay
MV001 Song Chuan Middle Voltage Relay
SKU:SON-30d641
Versatile and efficient medium-voltage relay for reliable electrical control. Certified by TUV and UL.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
MV001 Song Chuan Middle Voltage Relay
$39.99
Quantity: 1
Claim Your Seller Account
MV001 Song Chuan Middle Voltage Relay
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The MV001 Song Chuan Middle Voltage Relay is a reliable and high-performance electrical component designed for various applications. With a compact outline of 21.5mm x 16mm x 20.6mm, this relay features a contact configuration of 1A and a maximum allowable contact current of 15A, making it ideal for medium-voltage electrical systems. Its DC coil voltage range of 12 to 48V and low power consumption of 2W ensure efficient operation. This relay is certified by the Association for Technical Inspection (TUV) and Underwriters Laboratories (UL) for safety and quality assurance.
Product Specifications
Specifications Ac Dielectric Strength Between Contact And Coil
750 V
Specifications Ac Dielectric Strength Between Open Contact
750 V
Specifications Contact Configuration
1A
Specifications Contact Rating Resistive Load At 48 Volts V Dc Vo
15 A
Specifications Dc Coil Voltage
12 to 48 V
Specifications Dc Power Consumption
2 W
Specifications Electrical Life Expectancy
3 x 104 min
Specifications Maximum Allowable Contact Current
15 A
Specifications Mechanical Life Expectancy
2 x 105 min
Specifications Outline Height
20.6 mm
Specifications Outline Length
21.5 mm
Specifications Outline Width
16 mm
Specifications Safety Approval
Association for Technical Inspection (TUV) | Underwriters Laboratories (UL)
