NAB Standard White Wire Duct - 3x1.5 in
NAB Standard White Wire Duct - 3x1.5 in
SKU:NOR-ca78bb
Customizable North American Base Standard Wire Duct for efficient and secure wire management
Regular price
$45.99
Regular price
Sale price
$45.99
Unit price
per
Initiate Order
NAB Standard White Wire Duct - 3x1.5 in
$45.99
Quantity: 1
Claim Your Seller Account
NAB Standard White Wire Duct - 3x1.5 in
$45.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The NAB Standard White Wire Duct, with a nominal width of 3 inches and nominal height of 1.5 inches, offers a customizable solution for efficient wire management. Featuring expandability, retrofittability, and reusable design, this duct ensures cost-effective and time-efficient installations. Its restricted slot opening securely holds wires, and the burr-free edges prevent wire damage. With recessed mounting holes for quick component installation and break lines for easy customization, this duct is a versatile choice for panel and enclosure wiring needs.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Advantages Advantages
Customizable: length, fingers, hole patterns, and adhesive backing!Expandable and retrofittableCost, resource, and time-efficientReusableRestricted slot opening retains wire betterTwo pre-determined break lines for easily removing finger or finger basesBurr-free edges wonât damage wiresRecessed mounting holes for fast component mounting
Specifications Actual Dimension E
0.31 in
Specifications Actual Dimension F
0.47 in
Specifications Actual Dimension H
1.57 in
Specifications Actual Dimension W
3.15 in
Specifications Color
White
Specifications Nominal Height
1-1/2 in | 40 mm
Specifications Nominal Width
3 in | 80 mm
Specifications Standard Carton Quantity
12
