NEMA 11 2-Phase Hybrid Stepping Motor - KV28 Series (1.8 Degree/Step)
NEMA 11 2-Phase Hybrid Stepping Motor - KV28 Series (1.8 Degree/Step)
SKU:STE-7493e3
High-performance NEMA 11 2-Phase Hybrid Stepping Motor with 1.8° step angle and 165mN·m holding torque.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
NEMA 11 2-Phase Hybrid Stepping Motor - KV28 Series (1.8 Degree/Step)
$39.99
Quantity: 1
Claim Your Seller Account
NEMA 11 2-Phase Hybrid Stepping Motor - KV28 Series (1.8 Degree/Step)
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The NEMA 11 KV28 Series 2-Phase Hybrid Stepping Motor offers exceptional performance and precision with a step angle of 1.8 degrees/step. With a voltage per phase of 3.15V and a holding torque of 165 mN·m, this motor is ideal for applications requiring accuracy and reliability. Its compact design and high-quality construction ensure durability and efficiency, making it suitable for medical devices, security equipment, and more.
Product Specifications
Additional Information 0
33
Customize 0
Custom Designs
Dimensions 0
34
Specifications Ambient Temperature Range
-10 ~ +50 ºC
Specifications Application
FAMedical DevicesSecurity equipment
Specifications Current Per Phase
1.5 A
Specifications Dielectric Strength
500 V AC, 50 Hz for 1 min (at normal temp. & humidity, between lead and case)
Specifications Holding Torque
165 mN·m
Specifications Humidity Range For Ambient Temperature
5 ~ 95 % RH (noncondensing)
Specifications Humidity Range For Storage Temperature
5 ~ 95 % RH (noncondensing)
Specifications Inductance Per Phase
1.7 mH/PH
Specifications Insulation Resistance
500 V DC 100 MO min. (at normal temp. and humidity, between lead and case)
Specifications Max Temperature Rise By Resistance Method
80 ºK
Specifications Motor Frame Size
NEMA 11
Specifications Motor Length
51 in | 2.01 mm
Specifications Motor Mass
190 g
Specifications Options Available
Lead wire Assembly (Part# KV28LBS300)
Specifications Position Accuracy
±10 %
Specifications Resistance Per Phase
2.1 Ω
Specifications Rotor Inertia
22 g·cm²
Specifications Series
2 Phase Square KV
Specifications Series Code
KV28
Specifications Shaft Specification
Single Shaft
Specifications Step Angle
1.8 deg./step
Specifications Storage Temperature Range
-20 ~ +70 ºC
Specifications Type
2-Phase Hybrid Stepping Motor
Specifications Voltage Per Phase
3.15 V
Specifications Winding Method
Bipolar
Specifications Winding Resistance Per Phase
2.1 O
Torque Curve 0
32
