NEMA 17 3-Phase Hybrid Stepping Motor - KT Series (1.2 Degree/Step)
NEMA 17 3-Phase Hybrid Stepping Motor - KT Series (1.2 Degree/Step)
SKU:STE-936df3
High-performance NEMA 17 3-Phase Hybrid Stepping Motor for precise control and efficiency in industrial applications.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
NEMA 17 3-Phase Hybrid Stepping Motor - KT Series (1.2 Degree/Step)
$49.99
Quantity: 1
Claim Your Seller Account
NEMA 17 3-Phase Hybrid Stepping Motor - KT Series (1.2 Degree/Step)
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The NEMA 17 3-Phase Hybrid Stepping Motor from the KT Series offers unparalleled performance and precision. Ideal for applications requiring high torque at low speeds, this motor features a star winding connection for simplified drive circuitry, ultra-low vibration, and noise. With a micro-step driver offering step angle selections of 1/1, 1/2, 1/4, or 1/8, this motor ensures optimal control and efficiency. With a holding torque of 19.8 oz·in, this motor delivers superior performance and reliability. Measuring 42 x 34 mm, this motor is compact yet powerful, making it perfect for a wide range of industrial and automation applications.
Product Specifications
Additional Information 0
a2057.jpg | a2489.jpg | a2490.jpg | a2506.jpg | Explanation of Dynamic Torque Curves | KT42HM1-551 VIBRATION.jpg | KT60K.jpg
Customize 0
Custom Designs
Dimensions 0
Specifications Allowable Temperature Rise
70 ºK
Specifications Current Per 2 Phase
2.4 A
Specifications Detent Torque
1.4 oz·in | 10 mN·m
Specifications Dielectric Strength
500 VAC, 50 HZ, 1 min.
Specifications Drive Method
Bipolar
Specifications Holding Torque
19.8 oz·in | 140 mN·m
Specifications Inductance2 Phase
0.5 mH
Specifications Insulation Class
Jis Class E (120ºC/248ºF) (UL Value : Class B 130ºC/266ºF)
Specifications Insulation Resistance Motor Section
500 VDC, 100 MO min.
Specifications Motor Frame Size
NEMA 17
Specifications No Of Phases
3
Specifications Operating Temperature Range
-10 to 50 ºC
Specifications Product Type
Stepper Motor
Specifications Rotor Inertia
42 g·cm² | 0.23 oz·in²
Specifications Series
3 Phase KT
Specifications Standard Size
42 x 34 mm | 1.65 x 1.34 in.
Specifications Step Angle
1.2 deg./step
Specifications Type
KT Series, 3 phase Hybrid Stepping Motor
Specifications Voltage
2.60 V
Specifications Weight
210 g | 0.46 lb
Specifications Winding Resistance2 Phase
1.10 Ω
Torque Curve 0
KT42HM1-551 ST CURVE.jpg
