NEMA XX Natural Paper Phenolic Sheet
NEMA XX Natural Paper Phenolic Sheet
SKU:SHA-4a3bcc
Durable NEMA XX Natural Paper Phenolic Sheet with exceptional mechanical strength & electrical properties. Ideal for various applications.
Regular price
$89.99
Regular price
Sale price
$89.99
Unit price
per
Initiate Order
NEMA XX Natural Paper Phenolic Sheet
$89.99
Quantity: 1
Claim Your Seller Account
NEMA XX Natural Paper Phenolic Sheet
$89.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The NEMA XX Natural Paper Phenolic Sheet is a durable thermoset composite material known for its strength, resilience, and exceptional electrical properties. Manufactured by applying heat and pressure to layers of paper impregnated with synthetic resins, this material offers high mechanical and thermal performance. With a Rockwell hardness of M100, tensile strengths reaching up to 15,000 psi, and maximum operating temperature of 257°F, this phenolic laminate is ideal for various mechanical and electrical applications. Its versatility in fabrication, ease of machining, and resistance to softening upon re-heating make it a reliable choice for support components, insulating washers, switch bases, and more.
Product Specifications
Specifications Coefficient Of Thermal Expansion Crosswise
1.20 x 10-5 in/in/ºF
Specifications Coefficient Of Thermal Expansion Lengthwise
0.80 x 10-5 in/in/ºF
Specifications Compressive Strength
32000 psi
Specifications Density Astm D792
0.049 g/cm³
Specifications Dielectric Strength Short Time 0125 Astm D149
750 V/mil
Specifications Flammability Rating Ul 94
HB
Specifications Flexural Modulus Crosswise Astm D790
900000 psi
Specifications Flexural Modulus Lengthwise Astm D790
1100000 psi
Specifications Flexural Strength Crosswise Astm D790
13200 psi
Specifications Flexural Strength Lengthwise Astm D790
16000 psi
Specifications Hardness Rockwell Astm D785
M100
Specifications Izod Impact Strength Notched Crosswise Astm D256
0.60 ft·lb/in
Specifications Izod Impact Strength Notched Lengthwise Astm D256
0.65 ft·lb/in
Specifications Maximum Operating Temperature
257 ºF
Specifications Sheet Size
36 x 48 in
Specifications Tensile Strength Crosswise Astm D638
12000 psi
Specifications Tensile Strength Lengthwise Astm D638
15000 psi
Specifications Thickness
1.750 in
Specifications Tolerance
± 0.045 in
Specifications Weight
12.91 lb/ft²
