The NEMA XX Paper Phenolic Sheet in Natural color is a versatile thermoset composite known for its exceptional mechanical, thermal, and electrical properties. Manufactured using layers of paper impregnated with thermosetting resins that undergo a chemical reaction when heat and pressure are applied, resulting in a durable material that retains its shape and strength even under high impact and compressive forces. Ideal for a wide range of industrial applications, these phenolic laminates offer a unique combination of physical strength, resilience, and ease of fabrication. With outstanding electrical properties, this sheet is suitable for use in intricate punch parts, insulating washers, terminal boards, and other essential electrical components.
Product Specifications
Specifications Coefficient Of Thermal Expansion Crosswise
1.20 x 10-5 in/in/ºF
Specifications Coefficient Of Thermal Expansion Lengthwise
0.80 x 10-5 in/in/ºF
Specifications Compressive Strength
32000 psi
Specifications Density Astm D792
0.049 g/cm³
Specifications Dielectric Strength Short Time 0125 Astm D149
750 V/mil
Specifications Flammability Rating Ul 94
HB
Specifications Flexural Modulus Crosswise Astm D790
900000 psi
Specifications Flexural Modulus Lengthwise Astm D790
1100000 psi
Specifications Flexural Strength Crosswise Astm D790
13200 psi
Specifications Flexural Strength Lengthwise Astm D790
16000 psi
Specifications Hardness Rockwell Astm D785
M100
Specifications Izod Impact Strength Notched Crosswise Astm D256
0.60 ft·lb/in
Specifications Izod Impact Strength Notched Lengthwise Astm D256
0.65 ft·lb/in
Specifications Maximum Operating Temperature
257 ºF
Specifications Sheet Size
36 x 48 in
Specifications Tensile Strength Crosswise Astm D638
12000 psi
Specifications Tensile Strength Lengthwise Astm D638
15000 psi
Specifications Thickness
0.750 in
Specifications Tolerance
± 0.029 in
Specifications Weight
5.51 lb/ft²
