NG Series 16:11 N·m Gearbox
NG Series 16:11 N·m Gearbox
SKU:NGS-69a556
Dunkermotoren NG Series 16:11 N·m Gearbox - High efficiency, durable design for precision applications.
Regular price
$349.99
Regular price
Sale price
$349.99
Unit price
per
Initiate Order
NG Series 16:11 N·m Gearbox
$349.99
Quantity: 1
Claim Your Seller Account
NG Series 16:11 N·m Gearbox
$349.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The NG Series 16:11 N·m Gearbox by Dunkermotoren is a high-performance gear solution designed for applications requiring durability and efficiency. With an 85% efficiency rating and a reduction ratio of 16, this gearbox provides smooth operation and reliable power transmission. It features a continuous torque of 11 N·m, making it ideal for tasks demanding precision and strength. The gearbox's compact design and optional wheel lining in special materials ensure it meets various installation needs while maintaining a durable and robust construction. Ideal for industrial, government, and institutional applications.
Product Specifications
Features Features
Lifetime lubricationHigh efficiencyVibration resistanceHigh torqueLonglife version
Technical Specs Acceleration Torque
22 N·m
Technical Specs Axial Load
833 N
Technical Specs Brands
Dunkermotoren
Technical Specs Continuous Torque
11 N·m
Technical Specs Efficiency
85 %
Technical Specs Emergency Stop Torque
33 N·m
Technical Specs Maximum Backlash
35 arc-min
Technical Specs Number Of Stages
2
Technical Specs Operating Mode
S1 | S8
Technical Specs Product Availability
Preferred Series
Technical Specs Protection Class
Ingress Protection (IP54)
Technical Specs Radial Load
2500 N
Technical Specs Reduction Ratio
16
Technical Specs Series
NG
Technical Specs Weight Of Gearbox
4.5 kg
