NG Series 32: 11 Nm Gearbox

Name: NG Series 32: 11 Nm Gearbox
Brand: Dunkermotoren
SKU: NGS-dc0024
Price: 349.99 USD
Availability: OutOfStock

SKU:NGS-dc0024

NG Series 32: 11 Nm Gearbox - High-efficiency, durable gearbox with compact design and exceptional load capacity.

$349.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The NG Series 32 Reduction Ratio and 11 Newton-Meter (N·m) Continuous Torque Gearbox by Dunkermotoren is a preferred choice for those seeking high efficiency, durability, and precision. With an 85% efficiency rate, this gearbox boasts an outstanding radial load capacity of 2500 N and an axial load of 833 N. Its compact yet robust design requires minimal installation space, making it ideal for various applications. Featuring lifetime lubrication, vibration resistance, and a high torque capacity, this gearbox ensures reliable performance even in demanding conditions. Designed for S1 and S8 operating modes, this gearbox is IP54 rated for protection against ingress, meeting stringent industrial standards.

Product Specifications

Features Features

Lifetime lubricationHigh efficiencyVibration resistanceHigh torqueLonglife version

Technical Specs Acceleration Torque

22 NÂ·m

Technical Specs Axial Load

833 N

Technical Specs Brands

Dunkermotoren

Technical Specs Continuous Torque

11 NÂ·m

Technical Specs Efficiency

85 %

Technical Specs Emergency Stop Torque

33 NÂ·m

Technical Specs Maximum Backlash

35 arc-min

Technical Specs Number Of Stages

Technical Specs Operating Mode

S1 | S8

Technical Specs Product Availability

Preferred Series

Technical Specs Protection Class

Ingress Protection (IP54)

Technical Specs Radial Load

2500 N

Technical Specs Reduction Ratio

Technical Specs Series

Technical Specs Weight Of Gearbox

4.5 kg
