NG Series 4 Gearbox: Reduction Ratio 4, 11 Nm Continuous Torque

Name: NG Series 4 Gearbox: Reduction Ratio 4, 11 Nm Continuous Torque
Brand: Dunkermotoren
SKU: NGS-f4e26d
Price: 499.99 USD
Availability: OutOfStock

SKU:NGS-f4e26d

Powerful and durable NG Series 4 Gearbox with 90% efficiency, high torque capacity, and lifetime lubrication for reliable performance.

$499.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The NG Series 4 Reduction Ratio and 11 Nm Continuous Torque Gearbox by Dunkermotoren is a powerhouse of efficiency and durability. With a 90% efficiency rate and a lifetime lubrication feature, this gearbox ensures minimal maintenance and maximum performance. It boasts a high torque capacity of 11 Nm continuous torque, making it ideal for applications requiring reliable power transmission. Designed for longevity, vibration resistance, and high radial load capacity, this gearbox meets the demanding standards of both industrial and institutional procurement requirements.

Product Specifications

Features Features

Lifetime lubricationHigh efficiencyVibration resistanceHigh torqueLonglife version

Technical Specs Acceleration Torque

22 NÂ·m

Technical Specs Axial Load

833 N

Technical Specs Brands

Dunkermotoren

Technical Specs Continuous Torque

11 NÂ·m

Technical Specs Efficiency

90 %

Technical Specs Emergency Stop Torque

33 NÂ·m

Technical Specs Maximum Backlash

40 arc-min

Technical Specs Number Of Stages

Technical Specs Operating Mode

S1 | S8

Technical Specs Product Availability

Standard Product

Technical Specs Protection Class

Ingress Protection (IP54)

Technical Specs Radial Load

2500 N

Technical Specs Reduction Ratio

Technical Specs Series

Technical Specs Weight Of Gearbox

3.8 kg
