NG Series 5:1 Gearbox with 9 Nm Torque

Name: NG Series 5:1 Gearbox with 9 Nm Torque
Brand: Dunkermotoren
SKU: NGS-a4f6ec
Price: 499.99 USD
Availability: OutOfStock

SKU:NGS-a4f6ec

Upgrade your machinery with the NG Series 5:1 Gearbox for high torque and efficiency. Ideal for industrial applications.

$499.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Enhance your machinery with the NG Series 5:1 Gearbox featuring 9 Nm continuous torque and high efficiency. Built by Dunkermotoren, this gearbox boasts a durable design, exceptional radial load capacity, and optional wheel lining for added versatility. With features like lifetime lubrication, vibration resistance, and longlife version, this gearbox ensures reliable performance and longevity, making it an ideal choice for industrial applications. The NG Series Gearbox is designed to meet the rigorous standards of institutional buyers, providing outstanding performance in a compact footprint.

Product Specifications

Features Features

Lifetime lubricationHigh efficiencyVibration resistanceHigh torqueLonglife version

Technical Specs Acceleration Torque

18 NÂ·m

Technical Specs Axial Load

833 N

Technical Specs Brands

Dunkermotoren

Technical Specs Continuous Torque

9 NÂ·m

Technical Specs Efficiency

90 %

Technical Specs Emergency Stop Torque

27 NÂ·m

Technical Specs Maximum Backlash

40 arc-min

Technical Specs Number Of Stages

Technical Specs Operating Mode

S1 | S8

Technical Specs Product Availability

Standard Product

Technical Specs Protection Class

Ingress Protection (IP54)

Technical Specs Radial Load

2500 N

Technical Specs Reduction Ratio

Technical Specs Series

Technical Specs Weight Of Gearbox

3.8 kg
