NG Series Gearbox - 20:1 Reduction Ratio, 11 Nm Continuous Torque
NG Series Gearbox - 20:1 Reduction Ratio, 11 Nm Continuous Torque
SKU:NGS-883f47
NG Series 20:1 Reduction Ratio Gearbox - High efficiency, durability, and exceptional load capacity.
Regular price
$569.99
Regular price
Sale price
$569.99
Unit price
per
Initiate Order
NG Series Gearbox - 20:1 Reduction Ratio, 11 Nm Continuous Torque
$569.99
Quantity: 1
Claim Your Seller Account
NG Series Gearbox - 20:1 Reduction Ratio, 11 Nm Continuous Torque
$569.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The NG Series 20:1 Reduction Ratio Gearbox by Dunkermotoren is a preferred choice for its high efficiency, lifetime lubrication, and exceptional radial load capacity. With an 85% efficiency rating, 2 stages, and a continuous torque of 11 Nm, this gearbox offers reliable performance in S1 | S8 operating modes. Designed for durability, it can withstand axial loads of up to 833 N and radial loads of 2500 N. Ideal for applications requiring Ingress Protection (IP54) and compliance with industry standards.
Product Specifications
Features Features
Lifetime lubricationHigh efficiencyVibration resistanceHigh torqueLonglife version
Technical Specs Acceleration Torque
22 N·m
Technical Specs Axial Load
833 N
Technical Specs Brands
Dunkermotoren
Technical Specs Continuous Torque
11 N·m
Technical Specs Efficiency
85 %
Technical Specs Emergency Stop Torque
33 N·m
Technical Specs Maximum Backlash
35 arc-min
Technical Specs Number Of Stages
2
Technical Specs Operating Mode
S1 | S8
Technical Specs Product Availability
Preferred Series
Technical Specs Protection Class
Ingress Protection (IP54)
Technical Specs Radial Load
2500 N
Technical Specs Reduction Ratio
20
Technical Specs Series
NG
Technical Specs Weight Of Gearbox
4.5 kg
