Ni40/Fe40/Si+B19/Mo1-2 Foil - 0.025mm Thickness, Nickel/Iron Alloy
Ni40/Fe40/Si+B19/Mo1-2 Foil - 0.025mm Thickness, Nickel/Iron Alloy
SKU:NIC-e04cb6
Premium Ni40/Fe40/Si+B19/Mo1-2 Foil - Superior strength & magnetic properties, 0.025mm thickness. Ideal for diverse industrial uses.
Regular price
$99.99
Regular price
Sale price
$99.99
Unit price
per
Initiate Order
Ni40/Fe40/Si+B19/Mo1-2 Foil - 0.025mm Thickness, Nickel/Iron Alloy
$99.99
Quantity: 1
Claim Your Seller Account
Ni40/Fe40/Si+B19/Mo1-2 Foil - 0.025mm Thickness, Nickel/Iron Alloy
$99.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Ni40/Fe40/Si+B19/Mo1-2 Foil is a high-quality metallic glass alloy designed for soft magnetic applications, brazing, coating, and reinforcing fibers. With a thickness of 0.025mm and a Vickers hardness of 800 Kgf mm-2, this foil offers superior tensile strength ranging from 1500.00 to 2000.00 MPa. Its excellent magnetic properties including a saturation flux density of 0.80 T and electrical resistivity of 135 µΩ·cm make it ideal for various industrial applications. Compliant with industry standards, this foil ensures reliable performance and durability.
Product Specifications
Electrical Properties Electrical Resistivity
135 µΩ·cm
Magnetic Properties Coercivity As Cast
< 1.00 A m-1
Magnetic Properties Curie Temperature
260 ºC
Magnetic Properties Remanence Ratio Brbs
< 1.00
Magnetic Properties Saturation Flux Density
0.80 T
Magnetic Properties Saturation Magnetostriction
8 x10-6
Material Material
Nickel/Iron/Silicon/BoronMetallic glass (glassy alloy) or amorphous metal. Uses include soft magnetic applications, brazing, coating and as reinforcing fibers.
Mechanical Properties Hardness Vickers
800 Kgf mm-2
Mechanical Properties Tensile Modulus
150.00 GPa
Mechanical Properties Tensile Strength
1500.00 to 2000.00 MPa
Physical Properties Density
7.400 g·cm-3
Specifications Coil Width
25 mm
Specifications Form
Foil
Specifications Grade
Metallic Glass
Specifications Thickness
0.025 mm
Thermal Properties Crystallization Temperature
450 ºC
Thermal Properties Maximum Use Temperature In Air
120 ºC
Tolerances Tolerance For 001 Millimeter Mm Thickness
25 %
Tolerances Tolerance For 005 Millimeter Mm Thickness
10 %
Tolerances Tolerance For 100 Millimeter Mm Coil Length
+2 % | -1 %
Tolerances Tolerance For 100 Millimeter Mm Disc Diameter
+2 % | -1 %
Tolerances Tolerance For 100 Millimeter Mm Length 1 Light Tight
+2 % | -1 %
Tolerances Tolerance For 100 Millimeter Mm Length 2 Light Tight
+2 % | -1 %
Type Type
GlassGoodfellow offers two distinct types of glass products: The first are generally silica-based, non-crystalline (amorphous) solids which exhibit a glass transition and are brittle and transparent. The properties of glass materials can be readily modified to alter their optical performance and other characteristics. This type is available through Goodfellow's Ceramic and Glass Division. Generally, these products are made to order for customers, so we do not list them in our Catalog. Please contact us with your requirements. The second type of glass product is commonly referred to as "metallic glasses" or "glassy metals". In contrast to crystalline metals and alloys with highly ordered atomic structures, these are non-crystalline (amorphous) metals or, more usually, alloys. Our website details those glassy metals which are available from stock; please contact us if you are unable to find the item you specifically require.
