Designed to monitor and alarm for nitrogen oxide (NO) levels in ambient air near industrial sites, manufacturing facilities, combustion processes, etc. The NO sensor is of the disposable electrochemical type with an expected life of between 3-4 years. The sensor needs no warm up time and is ready to go as soon as the monitor is turned on.Model 575P has a built-in pump that can pull a sample through tubing from another area.
Product Specifications
Applications 0
Designed to monitor and alarm for nitrogen oxide (NO) levels in ambient air near industrial sites, manufacturing facilities, combustion processes, etc.
Features 0
Standard electrochemical cellFast response to the presence of chlorine in the airInstant warm-up, no waitBright digital readout - no reading interpretation errorsOptional - Built in 'Sonalert' audible alarmOptional - Two levels of alarm: 'Alert' and 'Alarm,' audible alarm can be silenced with 'Acknowledge' buttonEasy use and calibrateEasy to maintain modular layout4-20mA output signal for recordingNEMA 12 fiberglass enclosure is standard
Options 0
'Fail Safe' alarms availableStrobe lightLow flow alarmNEMA 4 or 4X enclosuresCold weather package for operation to -5°F (-20°C)
Specifications Accuracy Repeatability
±1% of full scale or 2 PPM, which ever is higher
Specifications Alarms
Optional - Audible alarm with 'Acknowledge' button | Optional - Dual high alarm light and relays (SPDT - 5A@ 230 VAC)
Specifications Ambient Temperature Range
32 to 120°F (0 to 40°C), may be operated at lower temperature with auxiliary heater
Specifications Drift
±1% of full scale or 2 PPM per week, whichever is greater
Specifications Linearity
±1% of full scale or 1 PPM, which ever is higher
Specifications Method Of Detection
Disposable electrochemical cell (3-4 years)
Specifications Output Options
0-1 VDC | 4-20 mA
Specifications Power
115 VAC, 60 Hz | 220 VAC, 50 Hz
Specifications Ranges Available
0-20 PPM standard
Specifications Resolution
1 PPM
Specifications Response Time T 90
Less than 15 seconds to 90% step change
Specifications Size Weight
14" H x 12" W x 8" D (35.6 x 30.5 x 20.3 cm) @ 18 lbs. (8.2 kg)
Unique Applications 0
All Nova analyzers are built using proven technologies and techniques. If this product does not suit your application, please contact Nova. In many cases, we are able to build an analyzer specific to your needs.
