Nitrogen Oxide Alarm Monitor, diffusion sensor
Nitrogen Oxide Alarm Monitor, diffusion sensor
SKU:BYP-71a8e0
N/A
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Nitrogen Oxide Alarm Monitor, diffusion sensor
$49.99
Quantity: 1
Claim Your Seller Account
Nitrogen Oxide Alarm Monitor, diffusion sensor
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Designed to monitor and alarm for nitrogen oxide (NO) levels in ambient air near industrial sites, manufacturing facilities, combustion processes, etc. The NO sensor is of the disposable electrochemical type with an expected life of between 3-4 years. The sensor needs no warm up time and is ready to go as soon as the monitor is turned on.Model 575D has one built-in diffusion-style sensor.
Product Specifications
Applications 0
Designed to monitor and alarm for nitrogen oxide (NO) levels in ambient air near industrial sites, manufacturing facilities, combustion processes, etc.
Calibration 0
Ambient air for O2 and to zero all other gasesAnalyzed calibration gas with representative concentrations for span of all other gases
Features 0
Standard electrochemical cellInstant warm-up, no waitBright digital readout - no reading interpretation errors.Easy use and calibrateEasy to maintain modular layout4-20mA output signal for recordingNEMA 12 fiberglass enclosure is standard
Options 0
'Fail Safe' alarms availableStrobe lightNEMA 4 or 4X enclosuresCold weather package for operation to -5°F (-20°C)
Specifications Accuracy Repeatability
±1% of full scale or 1 PPM, whichever is higher
Specifications Ambient Temperature Range
32 to 120°F (0 to 40°C), may be operated at lower temperature with auxiliary heater
Specifications Drift
Less than 1% of full scale or 2 PPM per week, whichever is greater
Specifications Linearity
±1% of full scale or 1 PPM, which ever is higher
Specifications Method Of Detection
Disposable electrochemical cell
Specifications Output Options
0-1 VDC | 4-20 mA
Specifications Power
115 VAC, 60 Hz | 220 VAC, 50 Hz
Specifications Ranges Available
0-20 PPM standard
Specifications Resolution
1 PPM
Specifications Response Time T 90
Less than 15 seconds to 90% step change
Specifications Size Weight
14" H x 12" W x 8" D (35.6 x 30.5 x 20.3 cm) @ 18 lbs. (8.2 kg)
Unique Applications 0
All Nova analyzers are built using proven technologies and techniques. If this product does not suit your application, please contact Nova. In many cases, we are able to build an analyzer specific to your needs.
