Non-Magnetic Sine Plate, 15° Angle, SAE .8620 Steel, 6x18 in²
Non-Magnetic Sine Plate, 15° Angle, SAE .8620 Steel, 6x18 in²
SKU:NON-0d681c
Precision non-magnetic sine plate for accurate angling and secure holding in industrial applications.
Regular price
$799.99
Regular price
Sale price
$799.99
Unit price
per
Initiate Order
Non-Magnetic Sine Plate, 15° Angle, SAE .8620 Steel, 6x18 in²
$799.99
Quantity: 1
Claim Your Seller Account
Non-Magnetic Sine Plate, 15° Angle, SAE .8620 Steel, 6x18 in²
$799.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Non-Magnetic Single Angle Sine Plate is a precision tool designed for applications where magnetic holding is impractical. Crafted from durable SAE .8620 steel, this plate features a 15° angle, a surface area of 6 x 18 square inches, and 27 holes with a 1/4-20 tapped hole pattern. With a height of 3 inches and a weight of 76 pounds, it offers exceptional stability and accuracy. Hardened to 58-60 Rockwell C, this plate ensures reliable performance and longevity. Compliant with SAE standards, it meets the rigorous requirements of industrial and institutional settings.
Product Specifications
Specifications Height
3 in
Specifications Material Hardness
58 to 60 Rockwell C
Specifications Number Of Holes
27
Specifications Plate And Roll Material
SAE .8620 Steel
Specifications Sine
15.000
Specifications Standards
SAE
Specifications Surface Area
6 x 18 in²
Specifications Tapped Hole Pattern
1/4-20
Specifications Weight
76 lb
