Noryl Rod for Fluid Handling & Electrical Applications
Noryl Rod for Fluid Handling & Electrical Applications
SKU:NOR-570b1d
High-performance Noryl Rod for fluid handling, electrical applications. Excellent electrical properties, low water absorption, UL 94 V-1 fire rating. Ideal for industrial use.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
Noryl Rod for Fluid Handling & Electrical Applications
$39.99
Quantity: 1
Claim Your Seller Account
Noryl Rod for Fluid Handling & Electrical Applications
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Experience superior performance with our Noryl Rod, a PPO-modified material stocked as Noryl Rod® and Noryl Sheet®. Ideal for fluid handling applications, it boasts very low moisture absorption, surpassing Acetal and PET with a better UL rating. With excellent electrical properties, fire retardant ratings, and low water absorption, this vacuum formable material excels in high dielectric strength applications. Available in Sheet or Rod, it offers machining to tight tolerances, stability, low thermal expansion, and a UL 94 V-1 fire rating at 0.058" thickness. Perfect for fluid handling, electrical housings, and flame retardant parts in a range of industrial environments.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Applications Applications
Applications - Frequently used in:Fluid Handling, Pump and Valve - Low Moisture PartsElectrical Housings, Cases and ComponentsInstrumentation and Semiconductor ComponentsHigh Continuous Temperature Environments (185ºF & 265ºF)Flame Retardant Parts Needing UL-94 V-1 (at 0.058" thickness)
Basics Basics
Why you should use Noryl®:It has Excellent Electrical PropertiesHas Excellent Fire Retardant RatingHas Extremely Low Water AbsorptionIs Vacuum Formable, Machinable and BondableHas Good Temperature Resistance. High Continuous Temperature - 185ºF & 265ºFReadily available in Sheet or RodExcellent Machining To Tight TolerancesDimensionally stable and Low Thermal ExpansionExcellent FR Rating - UL 94 V-1 @ 0.058" thick
Notes Notes
These Properties are for evaluation purposes only. This information is not to be construed as a warranty, guarantee or assurance that you may achieve the same results. Materials made from different resin types, manufacturing techniques and manufacturers will react differently. The information should be used to compare against other materials only, and each user should make his own tests to determine suitability. No warranty as to this materials suitability are either expressed or implied.
Size Tolerances Size Tolerances
Materials Available As:Noryl Sheet:0.060" - 6" thick in 48" x 96" Sheets -EN-265 (Black only)1/8", 3/16", and 1/4" in 48" x 96" with Haircell finish one side in EN-185 (White or Black)Film: 0.002" - 0.029" in up to 26" wide rolls on special order basisNoryl Rod: 1/8" - 8" diameter up to 96" lengthsSpecial Formulations:Glass Filled, Static Dissipative, Custom sizes, or Formulations
Specifications Color
Black, EN265
Specifications Diameter
3/4 in
Specifications Dimensions
48 in long piece
Specifications Quantity
1
