NOSHOK 1/2" Brass Thermowell - Straight Shank, 4" Length
NOSHOK 1/2" Brass Thermowell - Straight Shank, 4" Length
SKU:NOS-797fea
Durable NOSHOK Brass Thermowell for high-pressure environments, featuring 1/2" NPSM instrument connection, 4" length, and 5,000 psi pressure ratings.
Regular price
$45.99
Regular price
Sale price
$45.99
Unit price
per
Initiate Order
NOSHOK 1/2" Brass Thermowell - Straight Shank, 4" Length
$45.99
Quantity: 1
Claim Your Seller Account
NOSHOK 1/2" Brass Thermowell - Straight Shank, 4" Length
$45.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The NOSHOK 1/2" Brass Thermowell features a straight shank design with a 4" length, ideal for installations where temperature instruments need to be replaced without process shutdown. Built for durability and protection, it offers a 1/2" NPSM instrument connection and a 1/2" NPT process connection, with additional options available. With pressure ratings up to 5,000 psi, a bore size of 0.260", and materials like brass, this thermowell is suitable for high-pressure, corrosive, or abrasive environments. Perfect for HVAC, petrochemical, oil and gas industries, it ensures reliable temperature measurements.
Product Specifications
Additional Information Additional Information
The Female thread will accept the 1/2" NPT Male thread without galling or seizingBrass, 304 Stainless Steel, or 316 Stainless Steel standard material options - other options availableStandard style is stepped, available in straight, tapered and lagging optionsMultiple lagging lengths available
Application Application
Recommended wherever the process being measured is under pressure, corrosive, abrasive, or moving at a high velocityHVACPetrochemicalOil and gasProcess (flanged thermowells)
Limitations Which Apply Are Limitations Which Apply Are
These units must be operated within the catalogued environmental and application parameters. Determination of failure will be made by NOSHOK, Inc.'s equipment and personnel or a certified test facility specializing in this type of evaluation.In keeping with and for purposes of product and/or manufacturing process improvements, NOSHOK, Inc. reserves the right to make design changes without prior notice.
Note Note
Flange Connection not available.
Prop 65 Warnings Prop 65 Warnings
WARNING: This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Specifications Bore Size
0.260 in | 6.35 mm
Specifications Insertion Diameter B Max
3/4 in | 19.05 mm
Specifications Instrument Connection Size
1/2 in
Specifications Instrument Connection Type
National Pipe Straight Mechanical (NPSM)
Specifications Material
Brass
Specifications Pressure Ratings At 70 Degree Fahrenheit F
5,000 psi
Specifications Process Connection Size
1/2 in
Specifications Process Connection Type
National Pipe Thread (NPT)
Specifications Shank Diameter Max
0.750 in | 19.05 mm
Specifications Stem Length
4 in
Specifications Stock
Yes
Specifications Style
Straight Shank
Specifications Type
Thermowell
Specifications Warranty
1 y
