The NOSHOK 1" NPT Stainless Steel Thermowell is designed to facilitate easy removal and replacement of temperature instruments without process shutdown. Constructed from 316 stainless steel, this thermowell offers excellent protection to operators and minimizes instrument damage. With features like a 1/2" NPSM instrument connection, 2-1/2" stem length, and 7,000 psi pressure rating, it is ideal for pressure, corrosive, and high-velocity applications in industries such as HVAC, petrochemical, and oil & gas. This thermowell complies with industry standards for durability and safety.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Additional Information Additional Information
The Female thread will accept the 1/2" NPT Male thread without galling or seizingBrass, 304 Stainless Steel, or 316 Stainless Steel standard material options - other options availableStandard style is stepped, available in straight, tapered and lagging optionsMultiple lagging lengths available
Application Application
Recommended wherever the process being measured is under pressure, corrosive, abrasive, or moving at a high velocityHVACPetrochemicalOil and gasProcess (flanged thermowells)
Limitations Which Apply Are Limitations Which Apply Are
These units must be operated within the catalogued environmental and application parameters. Determination of failure will be made by NOSHOK, Inc.'s equipment and personnel or a certified test facility specializing in this type of evaluation.In keeping with and for purposes of product and/or manufacturing process improvements, NOSHOK, Inc. reserves the right to make design changes without prior notice.
Note Note
Flange Connection not available.To order a Flange Connection, you must specify Option RF1 or RF2. Flange Connections available only in Stainless steel.
Prop 65 Warnings Prop 65 Warnings
WARNING: This product can expose you to chemicals including Nickel, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
Specifications Bore Size
0.260 in | 6.35 mm
Specifications Insertion Diameter B Max
3/4 in | 19.05 mm
Specifications Instrument Connection Size
1/2 in
Specifications Instrument Connection Type
National Pipe Straight Mechanical (NPSM)
Specifications Material
316 Stainless Steel
Specifications Pressure Ratings At 70 Degree Fahrenheit F
7,000 psi
Specifications Process Connection Size
1 in
Specifications Process Connection Type
National Pipe Thread (NPT), Flange
Specifications Shank Diameter Max
0.750 in | 19.05 mm
Specifications Stem Length
2-1/2 in
Specifications Stock
Yes
Specifications Style
Straight Shank
Specifications Type
Thermowell
Specifications Warranty
1 y
