NOSHOK 3/4
NOSHOK 3/4
SKU:NOS-9b599b
Versatile NOSHOK Thermowell for high-pressure, corrosive, or abrasive temperature measurement applications. Easy instrument removal without process shutdown. 304 Stainless Steel construction for durability and operator protection.
Regular price
$77.57
Regular price
Sale price
$77.57
Unit price
per
Initiate Order
NOSHOK 3/4
$77.57
Quantity: 1
Claim Your Seller Account
NOSHOK 3/4
$77.57
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The NOSHOK 3/4" National Pipe Thread (NPT) Stepped Shank Thermowell with a 6" Length and 1/2" National Pipe Straight Mechanical (NPSM) Instrument Connection is designed for applications where the process is under pressure, corrosive, abrasive, or at high velocity. Made of 304 stainless steel, this thermowell allows for easy removal and replacement of temperature instruments without process shutdown. It provides operator protection and minimizes the risk of damage to the temperature instrument. With various connection types available, including 1/2" NPT, 1" NPT, flanged, and sanitary options, this thermowell offers versatility and reliability for temperature measurement in HVAC, petrochemical, oil and gas, and process industries. Pressure-rated at 7,000 psi and featuring a bore size of 0.260 inches, the NOSHOK thermowell ensures durability and precision in temperature sensing applications.
Product Specifications
Additional Information Additional Information
The Female thread will accept the 1/2" NPT Male thread without galling or seizingBrass, 304 Stainless Steel, or 316 Stainless Steel standard material options - other options availableStandard style is stepped, available in straight, tapered and lagging optionsMultiple lagging lengths available
Application Application
Recommended wherever the process being measured is under pressure, corrosive, abrasive, or moving at a high velocityHVACPetrochemicalOil and gasProcess (flanged thermowells)
Limitations Which Apply Are Limitations Which Apply Are
These units must be operated within the catalogued environmental and application parameters. Determination of failure will be made by NOSHOK, Inc.'s equipment and personnel or a certified test facility specializing in this type of evaluation.In keeping with and for purposes of product and/or manufacturing process improvements, NOSHOK, Inc. reserves the right to make design changes without prior notice.
Prop 65 Warnings Prop 65 Warnings
WARNING: This product can expose you to chemicals including Nickel, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
Specifications Bore Size
0.260 in | 6.35 mm
Specifications Insertion Diameter B Max
3/4 in | 19.05 mm
Specifications Instrument Connection Size
1/2 in
Specifications Instrument Connection Type
National Pipe Straight Mechanical (NPSM)
Specifications List Price
77.57 USD
Specifications Material
304 Stainless Steel
Specifications Pressure Ratings At 70 Degree Fahrenheit F
7,000 psi
Specifications Process Connection Size
3/4 in
Specifications Process Connection Type
National Pipe Thread (NPT)
Specifications Shank Diameter Max
0.750 in | 19.05 mm
Specifications Stem Length
6 in
Specifications Stock
Yes
Specifications Style
Stepped Shank
Specifications Type
Thermowell
Specifications Warranty
1 y
