NOSHOK 800 Series 6" Precision Test Gauge
NOSHOK 800 Series 6" Precision Test Gauge
SKU:NOS-c8bdc3
Accurate and reliable 6" precision test gauge for aerospace, laboratories, and gauge repair facilities.
Regular price
$897.98
Regular price
Sale price
$897.98
Unit price
per
Initiate Order
NOSHOK 800 Series 6" Precision Test Gauge
$897.98
Quantity: 1
Claim Your Seller Account
NOSHOK 800 Series 6" Precision Test Gauge
$897.98
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The NOSHOK 800 Series 6" Precision Test Gauge is designed for unparalleled accuracy and reliability in pressure measurement. With a durable 304 stainless steel case and precision-engineered copper alloy internals, this gauge offers a pressure range of 0 to 600 psi. The 1/4" NPT bottom connection and adjustable knife-edge pointer ensure easy installation and precise readings. Ideal for aerospace equipment, gauge repair facilities, and laboratory use, this gauge is suitable for static pressure applications up to 100% of the dial range. Compliant with rigorous industry standards and backed by a 1-year warranty, the NOSHOK 800 Series is a top choice for precision measurement needs.
Product Specifications
Application Application
Aerospace equipmentGauge repair facilitiesLaboratory & test equipmentPrecision measurement
Caution Caution
Operating conditions including, but not limited to, system pressure, media compatibility and ambient conditions must be considered when selecting gauges and accessories. Improper selections and use of gauges could possibly cause gauge failure and lead to possible property damage or personal injury. Refer to the American National Standard ANSI B40.1 for the correct selection and use of gauges. A copy of this standard may be obtained from the American Society of Mechanical Engineers, United Engineering Center, 345 East 47th Street, New York, NY 10017.In keeping with and for purposes of product and/or manufacturing process improvements, NOSHOK, Inc. reserves the right to make design changes without prior notice.
Limitations Which Apply Are Limitations Which Apply Are
Bourdon tube pressure gauges must be used within their calibrated maximum range to prevent damageThe pressure gauges must be operated within the following working pressure limits:Dynamic Pressure application, 60% of the dial rangeStatic Pressure applications, where no sharp fluctuations occur, 90% of the dial rangeThe gauges must be operated within specified ambient temperature rangesDetermination of gauge failures will be made by NOSHOK, Inc., which will use its equipment and personnel or a certified test facility specializing in this type of evaluation and determination. Gauge failures determined to be caused by over-range, incompatibility with environment or product media and abuse will not be considered under this warranty. NOSHOK, Inc. will, at its discretion, repair or replace the working parts of the damaged gauge without cost to the customer. This written warranty applies only to the NOSHOK gauges referenced in the first paragraph of this warranty, sold by NOSHOK, Inc. and its authorized distributors.
Options And Accessories Assembly Options
NOSHOK offers multiple assembly options to meet your specific system requirements. Consult factory to discuss your customized solution.
Options And Accessories Diaphragm Seals
NOSHOK offers a wide variety of standard & elevated pressure, and reduced pressure replaceable and non-replaceable diaphragm seals, designed to isolate and/or protect the pressure measuring instrument from corrosive, viscous, contaminated or very high temperature process media.
Options And Accessories Distribution Manifolds
NOSHOK's Distribution Manifolds connect multiple instruments to one diaphragm seal, eliminating multiple connections that lead to possible leak paths.
Options And Accessories Installed Options And Accessories
Available10-32-UNF-2B (10-32)Orifice - 316SS Threaded 0.8 mm (ST8) - StandardOrifice - 316SS Threaded 0.5 mm (ST5)Laser Marking (LM)Stainless Steel Tagging (ST)CertificatesCertified Calibration (CC), Vacuum through 15,000 psiCleaning for Oxygen Service (O2), Up to 1,000 psiCleaning for Oxygen Service (O2), 1,500 psi and up
Options And Accessories Metric Dials And Customized Special Dial
Dual scale metric dials in psi/bar, psi/kPa and psi/kg/cm2 Other scales are available for specific sizes and ranges, such as single scale bar and kPa, refrigerant scales and altitude scalesCustomized special dials such as non-standard metric scale, tons of ram, lbs. of force, etc. are available in small quantities (as few as one piece) on some NOSHOK gaugesPlease consult the factory for availability.
Options And Accessories Pressure Snubbers Piston Type
Resist clogging and are self-cleaningFive different sized pistons included with each snubber to ensure the correct amount of snubbing for virtually every applicationAvailable in Brass and 316 Stainless Steel in 1/4" NPT, 1/2" NPT or SAE J1926-3: 7/16-20Weight approximately 0.2 lb. for 1/4" & 7/16", and approximately 0.4 lb. for 1/2"ââââââ
Options And Accessories Pressure Snubbers Sintered Type
Cost effective solution to protect expensive instrumentationIncreases gauge readability by smoothing out pressure surges, pulsations and spikes5 basic elements available for each snubber to accommodate specific application needsSnubbing action achieved by utilizing a corrosion resistant 316 Stainless Steel sintered porous elementExotic materials or intermediate disc grades availableProvides long service life with no moving parts to wear outWeight approximately 0.2 lb. for 1/4" & 7/16", and approximately 0.4 lb. for 1/2
Options And Accessories Steam Syphons
Protect the instrument from the damaging effects of high temperature steamRecommended for use in all steam applicationsAvailable in 1/4" and 1/2" NPT sizes in welded steel, welded 316 Stainless Steel or seamless 316 Stainless Steel with ratings to 3,800 psi at 850 ºF
Options And Accessories Uninstalled Options And Accessories
Certificate of Cleaning (COCL)Certificate of Conformance (COC)
Prop 65 Warnings Prop 65 Warnings
WARNING: This product can expose you to chemicals including Lead and Nickel, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Specifications Ambient Temperature Range
-40 to 140 ºF | -40 to 60 ºC
Specifications Case Material
304 Stainless Steel
Specifications Case Type
Stainless Steel (SS) Case, Bottom Connection
Specifications Connection Location
Bottom
Specifications Connection Material
Brass
Specifications Connection Size
1/4 in
Specifications Connection Type
National Pipe Thread (NPT)
Specifications Cover Ring Material
304 Stainless Steel
Specifications Dial
Aluminum, white mirrored background with black scale.
Specifications Figure Primary Scale Pressure
50 psi
Specifications Full Scale Accuracy
0.25 %
Specifications Gauge Size
6 in
Specifications Graduation Primary Scale Pressure
2 psi
Specifications Lens
Instrument Glass
Specifications List Price
897.98 USD
Specifications Measuring Element
Beryllium copper Bourdon tube to 1,000 psi, 316 SS Bourdon tube 1,500 psi to 6,000 psi
Specifications Media Temperature Range
-40 to 180 ºF | -40 to 80 ºC
Specifications Movement
Brass with jeweled bearings nickel-silver pinion gear and shafts
Specifications Pointer
Adjustable Knife-Edge Pointer
Specifications Pressure Range
0 to 600 psig
Specifications Related Items
204-MFS, 1/2" National Pipe Thread (NPT), Male x Female, 316 Stainless Steel, 0.187" Orifice Hard Seat Multiport Valve | 2070-MFS, 1/2" National Pipe Thread (NPT), Male x Female, 316 Stainless Steel, Hard Seat, 0.187" Orifice Block and Bleed 2-Valve | 404-MFS, 1/2" National Pipe Thread (NPT), Male x Female, 316 Stainless Steel, Hard Seat, 0.187" Orifice Needle Valve | 704-MFS, 1/2" National Pipe Thread (NPT), Male x Female, 316 Stainless Steel, Soft Seat, 0.187" Orifice Block and Bleed Valve
Specifications Scale Option
psi Single Scale
Specifications Series
800
Specifications Stock
Yes
Specifications Type
Pressure Gauge
Specifications Warranty
1 y
Working Pressure Limitations Working Pressure Limitations
Static PressureThe working pressure, where no sharp fluctuations occur, should be limited to 100% of the dial range.NOTE: 800 Series Precision Test gauges are not intended for dynamic applications.
