Novaphit SSTC Flexible Graphite Gasket with Stainless Steel Wire Mesh Insert
Novaphit SSTC Flexible Graphite Gasket with Stainless Steel Wire Mesh Insert
SKU:FLE-3d0236
High-performance graphite gasket with stainless steel wire mesh insert for industrial applications. Resistant to gases, fluids, and corrosion.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Novaphit SSTC Flexible Graphite Gasket with Stainless Steel Wire Mesh Insert
$49.99
Quantity: 1
Claim Your Seller Account
Novaphit SSTC Flexible Graphite Gasket with Stainless Steel Wire Mesh Insert
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Stainless Steel Wire Mesh Inserted Novaphit SSTC Flexible Graphite Gasket is a high-performance sealing solution designed for industrial applications requiring impermeability to gases and fluids. With available thickness options of 0.020 in, 0.039 in, 0.059 in, and 0.079 in, and sheet sizes of 60 x 60 in and 39.37 x 39.37 in, this gasket excels in high-pressure, high-temperature, and mechanically demanding environments. Resistant to organic and inorganic acids, solvents, hot wax, and oils, it is ideal for sealing valves, shafts, flanges, and more. Please note, it is not suitable for use with strong oxidizing compounds like concentrated nitric acids or chromium (VI) solutions.
Product Specifications
Specifications Additional Note
60 x 60 Sheet Size for 1/8 and 1/16 Inch (in) Thick Sheet
Specifications Applications
Impermeable to gases and fluids, corrosion resistant | The best expanded graphite solution in high pressure and high temperature, mechanical loading applications: Resistant to organic, inorganic acids, solvents, hot wax and oils | Excellent for sealing high temperature valves, shafts, and flanges, high thermal conductivityExceptions are Strong oxidizing compounds such as:Concentrated nitric acids, high concentrated sulphuric acids, chromium (VI) and permanganate solutions,
Specifications Available Thickness
0.020 in | 0.039 in | 0.059 in | 0.079 in
Specifications Sheet Size
60 x 60 in | 39.37 x 39.37 in
