NSF Certified Food-Grade Liquid Tight Conduit - Type FG

Name: NSF Certified Food-Grade Liquid Tight Conduit - Type FG
Brand: Anamet Electrical, Inc.
SKU: LIQ-b77683
Price: 129.99 USD
Availability: OutOfStock

SKU:LIQ-b77683

NSF Certified liquid-tight conduit for food safety in washdown areas. Resistant to bacteria growth, easy to sterilize. Ideal for food processing facilities.

$129.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Ensure food safety with Type FG, the only NSF Certified liquid-tight conduit designed for food contact and washdown areas. Compliant with FDA CFR21 and NSF 51, the PVC jacket resists bacteria growth and can be easily sterilized. Ideal for food processing, pharmaceutical, and meat packing facilities, this conduit offers flexibility, durability, and easy installation with standard connectors.

Product Specifications

Application 0

Special purpose food equipment or devices. Wash down areas. Meat packing facilities Restaurants Food processing facilities Poultry packing facilities Pharmaceutical manufacturers

Places Of Interest 0

Food equipment or devices NSF/ ANSI 169Food Equipment Manufacturers SIC 3556Meat Packing SIC 2011 NAICS 311613Poultry SIC 2015 NAICS 311615Pharmaceuticals SIC 2834 NAICS 325412

Specifications Approx Inside Bend Radius

2.5 in | 63.5 mm

Specifications Approx Weight Per 100 Ft

25 lbs | 11.34 kg

Specifications Core Material

Galvanized Steel

Specifications Cross Reference

111019 | 111039 | 111049 | LTFG-11 | SZ02-30-00 | UL NSF S

Specifications Electrical Trade Size

1/2 in | 16 mm

Specifications Industry Certifications

NSF Component | RoHS WEEE

Specifications Ingress Protection Ip Rating

Ingress Protection (IP) 66/67

Specifications Inside Diameter

0.620 to 0.640 in | 15.748 to 16.256 mm

Specifications Jacket Benefits

Liquid Tight

Specifications Jacket Material

Polyvinyl Chloride (PVC)

Specifications Naed Pin

35512

Specifications Outside Diameter

0.820 to 0.840 in | 20.828 to 21.336 mm

Specifications Packaging

Standard Carton

Specifications Standard Length

100 ft | 30.48 m

NSF Certified Food-Grade Liquid Tight Conduit - Type FG
