NSF Certified Liquid-Tight SEALTITE® Conduit for Food Grade Applications

Name: NSF Certified Liquid-Tight SEALTITE® Conduit for Food Grade Applications
Brand: Anamet Electrical, Inc.
SKU: LIQ-04e85c
Price: 129.99 USD
Availability: OutOfStock

SKU:LIQ-04e85c

NSF Certified Type FG SEALTITE® Conduit - Hygienic, Durable, Bacteria Inhibiting for Food Grade Use

$129.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Experience unmatched hygiene and durability with the Type FG Bacteria Inhibiting SEALTITE® Conduit. NSF Certified for food contact and washdown areas, this conduit features a flexible thermoplastic PVC jacket that meets FDA CFR21 and NSF 51 requirements. With a range of trade sizes available and easy installation using standard liquid-tight connectors, this conduit is ideal for food processing facilities, restaurants, and pharmaceutical manufacturers. Prevent bacteria growth and ensure easy cleaning and sterilization with this high-quality conduit engineered for food-grade applications.

Product Specifications

Application 0

Special purpose food equipment or devices. Wash down areas. Meat packing facilities Restaurants Food processing facilities Poultry packing facilities Pharmaceutical manufacturers

Places Of Interest 0

Food equipment or devices NSF/ ANSI 169Food Equipment Manufacturers SIC 3556Meat Packing SIC 2011 NAICS 311613Poultry SIC 2015 NAICS 311615Pharmaceuticals SIC 2834 NAICS 325412

Specifications Approx Inside Bend Radius

2.0 in | 50.8 mm

Specifications Approx Weight Per 100 Ft

21 lbs | 9.53 kg

Specifications Core Material

Galvanized Steel

Specifications Cross Reference

101019 | 101039 | 101049 | LTFG-10 | SZ01-30-00 | UL NSF S

Specifications Electrical Trade Size

3/8 in | 12 mm

Specifications Industry Certifications

NSF Component | RoHS WEEE

Specifications Ingress Protection Ip Rating

Ingress Protection (IP) 66/67

Specifications Inside Diameter

0.485 to 0.505 in | 12.319 to 12.827 mm

Specifications Jacket Benefits

Liquid Tight

Specifications Jacket Material

Polyvinyl Chloride (PVC)

Specifications Naed Pin

35502

Specifications Outside Diameter

0.690 to 0.710 in | 17.526 to 18.034 mm

Specifications Packaging

Standard Carton

Specifications Standard Length

100 ft | 30.48 m
