NSF Certified Type FG Food Grade Liquid Tight Metal Conduit
NSF Certified Type FG Food Grade Liquid Tight Metal Conduit
SKU:LIQ-4d3fe5
NSF Certified Type FG Conduit: Ensures food safety with bacteria-inhibiting PVC jacket. Easy to clean and sterilize. Ideal for food & pharmaceutical industries.
Regular price
$99.99
Regular price
Sale price
$99.99
Unit price
per
Initiate Order
NSF Certified Type FG Food Grade Liquid Tight Metal Conduit
$99.99
Quantity: 1
Claim Your Seller Account
NSF Certified Type FG Food Grade Liquid Tight Metal Conduit
$99.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The NSF Certified Type FG SEALTITE® Conduit is designed for incidental food contact and washdown areas. It meets NSF/ ANSI 169 standards for special purpose food equipment, with a flexible thermoplastic PVC jacket that complies with FDA CFR21 and NSF 51 requirements. Featuring bacteria-inhibiting properties, this conduit is easy to clean and sterilize without jacket degradation. Available in trade sizes from 3/8” to 2” with easy installation using standard liquid-tight connectors. Ideal for food processing facilities, pharmaceutical manufacturers, and more.
Product Specifications
Application 0
Special purpose food equipment or devices. Wash down areas. Meat packing facilities Restaurants Food processing facilities Poultry packing facilities Pharmaceutical manufacturers
Places Of Interest 0
Food equipment or devices NSF/ ANSI 169Food Equipment Manufacturers SIC 3556Meat Packing SIC 2011 NAICS 311613Poultry SIC 2015 NAICS 311615Pharmaceuticals SIC 2834 NAICS 325412
Specifications Approx Inside Bend Radius
7.0 in | 177.8 mm
Specifications Approx Weight Per 100 Ft
136 lbs | 61.69 kg
Specifications Core Material
Galvanized Steel
Specifications Cross Reference
161029 | 161049 | LTFG-16 | SZ07-24-00 | UL NSF S
Specifications Electrical Trade Size
2 in | 53 mm
Specifications Industry Certifications
NSF Component | RoHS WEEE
Specifications Ingress Protection Ip Rating
Ingress Protection (IP) 66/67
Specifications Inside Diameter
2.020 to 2.045 in | 51.308 to 51.943 mm
Specifications Jacket Benefits
Liquid Tight
Specifications Jacket Material
Polyvinyl Chloride (PVC)
Specifications Naed Pin
35561
Specifications Outside Diameter
2.340 to 2.375 in | 59.436 to 60.325 mm
Specifications Packaging
Standard Carton
Specifications Standard Length
50 ft | 15.24 m
