NSF Certified Type FG Food Grade Liquid Tight Metal Conduit
NSF Certified Type FG Food Grade Liquid Tight Metal Conduit
SKU:LIQ-205a8c
NSF Certified liquid-tight metal conduit for food-grade applications. Inhibits bacteria growth, easy to clean, and install.
Regular price
$159.99
Regular price
Sale price
$159.99
Unit price
per
Initiate Order
NSF Certified Type FG Food Grade Liquid Tight Metal Conduit
$159.99
Quantity: 1
Claim Your Seller Account
NSF Certified Type FG Food Grade Liquid Tight Metal Conduit
$159.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Meet the highest standards of safety and hygiene with our NSF Certified Type FG Liquid-Tight Conduit. Ideal for food contact and washdown areas, this conduit features a flexible thermoplastic PVC jacket compliant with FDA CFR21 and NSF 51 regulations. Inhibits bacteria growth, easy to clean, and sterilize. Available in various trade sizes for easy installation with standard connectors.
Product Specifications
Application 0
Special purpose food equipment or devices. Wash down areas. Meat packing facilities Restaurants Food processing facilities Poultry packing facilities Pharmaceutical manufacturers
Places Of Interest 0
Food equipment or devices NSF/ ANSI 169Food Equipment Manufacturers SIC 3556Meat Packing SIC 2011 NAICS 311613Poultry SIC 2015 NAICS 311615Pharmaceuticals SIC 2834 NAICS 325412
Specifications Approx Inside Bend Radius
5.5 in | 139.7 mm
Specifications Approx Weight Per 100 Ft
104 lbs | 47.17 kg
Specifications Core Material
Galvanized Steel
Specifications Cross Reference
151029 | 151049 | LTFG-15 | SZ06-24-00 | UL NSF S
Specifications Electrical Trade Size
1-1/2 in | 41 mm
Specifications Industry Certifications
NSF Component | RoHS WEEE
Specifications Ingress Protection Ip Rating
Ingress Protection (IP) 66/67
Specifications Inside Diameter
1.575 to 1.600 in | 40.005 to 40.640 mm
Specifications Jacket Benefits
Liquid Tight
Specifications Jacket Material
Polyvinyl Chloride (PVC)
Specifications Naed Pin
35551
Specifications Outside Diameter
1.865 to 1.900 in | 47.371 to 48.260 mm
Specifications Packaging
Standard Carton
Specifications Standard Length
50 ft | 15.24 m
