NuPower Xtender™ C10RX01 Bidirectional Amplifier
NuPower Xtender™ C10RX01 Bidirectional Amplifier
SKU:NUP-292338
N/A
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
NuPower Xtender™ C10RX01 Bidirectional Amplifier
$49.99
Quantity: 1
Claim Your Seller Account
NuPower Xtender™ C10RX01 Bidirectional Amplifier
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The NuPower Xtender™ C10RX01 Bidirectional C-Band Amplifier module is a small, broadband, high-performance RF amplifier that generates 10 Watts of RF power across C-band frequencies of 4400 to 5100 MHz. The NuPower Xtender C10RX01 C-Band RF bidirectional amplifier is ideal for extending the communication range of half-duplex transceivers with constant-envelope waveforms (i.e. PSK- and FSK-based modulations, such as SOQPSK and GFSK), and generates 10 Watts of RF transmit power. In receive mode, the NuPower Xtender offers a low noise figure of 3.5 dB and a low noise amplifier that provides 12 dB of gain. The module accepts a nominal +30 dBm input level and provides 10 dB of transmit gain. The NuPower Xtender C10RX01 features a manual (T/R) mode selection, coupled with an extremely fast T/R mode switch time of 2 μS. An alternate configuration, the NuPower Xtender C10RX03, features autosense transmit / receive (T/R) mode selection for automatic transmit/receive switching. With a miniature form factor (3.57″ x 2.57″ x 0.50″ and 2.6 cubic inches) and state-of-the-art Gallium Nitride (GaN) power amplifier device technology, the NuPower Xtender C10RX01 Bidirectional C-Band PA module is ideal for broadband RF telemetry and communication systems that require reliability and minimal size, weight, and power consumption (SWaP).
Product Specifications
Specifications Export Classification
EAR99
Specifications Gain Typ
10 dB
Specifications Input Drive
30 dBM
Specifications Input Supply
27 - 32
Specifications Maximum Frequency
5100 MHz
Specifications Minimum Frequency
4400 MHz
Specifications Output Power Typ
10 W
Specifications Rf Connector Options
SMA
Specifications Size Lx W X H
3.57 x 2.57 x 0.50 Inch
Specifications Weight
2.6 oz
