Nylon Circuit Board Support - .062 PCB/.125 Chassis - Pack of 500
Nylon Circuit Board Support - .062 PCB/.125 Chassis - Pack of 500
SKU:01C-abf2d9
Secure Nylon Circuit Board Support for .062 PCB/.125 Chassis - Pack of 500, ASTM D 4066, RoHS, UL94V-2
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Nylon Circuit Board Support - .062 PCB/.125 Chassis - Pack of 500
$29.99
Quantity: 1
Claim Your Seller Account
Nylon Circuit Board Support - .062 PCB/.125 Chassis - Pack of 500
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Nylon Circuit Board Support is designed for use with .062-inch thick PCBs and .125-inch thick chassis, providing secure lock fit into both the PCB and chassis. Made of Nylon 66 UL94V-2 material, this pack contains 500 supports. It meets ASTM D 4066, PA111 standards, is RoHS compliant, and has a temperature range of -40 to 185F (-40 to 85C), with UL94V-0 option available. Ensure stability and durability for your electronic components with this reliable circuit board support.
Product Specifications
Specifications Board Thickness
.062 (1.6) inches (mm)
Specifications Chassis Thickness
.125 (3.17) inches (mm)
Specifications Dim L 015
.187 (4.8) inches (mm)
