Nylon Circuit Board Supports - Flat Board Side x .187 Chassis Hole, 500-Pack

Name: Nylon Circuit Board Supports - Flat Board Side x .187 Chassis Hole, 500-Pack
Brand: All Electronics Hardware
SKU: 01C-847789
Price: 29.99 USD
Availability: OutOfStock

SKU:01C-847789

Effortlessly install these durable Nylon Circuit Board Supports for densely loaded PC boards. RoHS compliant.

$29.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The 04A Series Nylon Circuit Board Supports offer effortless installation without the need for tools or screws, making them ideal for densely loaded PC boards. Made of Nylon 66 UL94V-2 material (UL94V-0 available), these supports are durable and reliable. With a panel range of 040-.078 inches, a packaging of 500 supports per bag, and a temperature range of -40 to 185F, these supports are versatile and compliant with ASTM D 4066, PA111, and RoHS standards.

Product Specifications

Specifications Chassis Thickness

040-.078 (1-1.9) inches (mm)

Specifications Color

Natural

Specifications Dim L

1.12 (28.6) inches (mm)

Specifications Mounting Hole Diameter

.187 (4.8) inches (mm)
