Nylon Sealing Plug with Neoprene Rubber O-Ring for Unified/Straight Threads, 1 5/8-12
Nylon Sealing Plug with Neoprene Rubber O-Ring for Unified/Straight Threads, 1 5/8-12
SKU:SEA-0ad653
Protect threaded ports with Nylon Sealing Plug for Unified/Straight Threads. High-resistance Yellow Nylon with Neoprene Rubber O-Ring ensures secure sealing.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Nylon Sealing Plug with Neoprene Rubber O-Ring for Unified/Straight Threads, 1 5/8-12
$29.99
Quantity: 1
Claim Your Seller Account
Nylon Sealing Plug with Neoprene Rubber O-Ring for Unified/Straight Threads, 1 5/8-12
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Nylon Sealing Plug with Neoprene Rubber O-Ring for Unified/Straight Threads by MOCAP is expertly designed to safeguard threaded ports and fittings from moisture, dust, and damage. Featuring five complete threads and a sealing lip, this plug ensures a secure seal. Constructed from high-resistance Yellow Nylon, it offers durability against hydraulic fluids, solvents, acids, and base alkalines. Perfect for applications requiring a flawless seal, the plug comes with a factory-fitted Neoprene Rubber O-Ring. Easily applied and removed manually or with tools, this plug is ideal for protecting threads during production, shipping, and storage.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Features 0
Our SPU Series Plugs are: Yellow Nylon (offers high resistance against hydraulic fluids, solvents, acids and base alkalines)Sized to fit Unified/Straight Threads from 7/16-20 to 1-5/8-12Neoprene Rubber O-Ring
Manufacturing Notes 0
MOCAP stocks sealing plugs for Unified/Straight Threads in both red polypropylene and yellow nylon materials in many sizes for immediate shipment.Micro-Packs are only available online.These Sealing Plugs are also available with a factory-fit Neoprene Rubber O-Ring when a perfect seal is required.
Specifications Box Quantity
500
Specifications Color
Yellow
Specifications Flange Outer Diameter Dimension A
2.280 in | 57.9 mm
Specifications Length Dimension C
0.670 in | 17.0 mm
Specifications Material
Nylon
Specifications Micro Pack Quantity
10
Specifications Mini Pack Quantity
100
Specifications O Ring Material
Neoprene Rubber
Specifications Standards
RoHS Compliant
Specifications Stem Height Dimension B
0.590 in | 15.0 mm
Specifications To Fit Standard Thread Size
1 5/8-12
