Nylon Support Posts for Circuit Boards - .187 Board Hole x .187 Chassis Hole

Name: Nylon Support Posts for Circuit Boards - .187 Board Hole x .187 Chassis Hole
Brand: All Electronics Hardware
SKU: 01C-ba0714
Price: 29.99 USD
Availability: OutOfStock

SKU:01C-ba0714

Durable Nylon Support Posts with .187 Board Hole x .187 Chassis Hole. Easy to install and remove, ASTM compliant.

$29.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The 21 Series Nylon Support Posts are designed for easy installation by hand with a secure locking mechanism for stability. These support posts feature a .187 Board Hole x .187 Chassis Hole dimension, ideal for circuit board supports. Made of Nylon 66 UL94V-2 material (UL94V-0 available), they meet ASTM D 4066 standards and are RoHS compliant. With a temperature range of -40 to 185F (-40 to 85C), these support posts offer durability and reliability for various applications.

Product Specifications

Specifications Boardchassis Hole Dia

.187 (4.8) inches (mm)

Specifications Dim L

.312 (7.92) inches (mm)

Specifications Material Code

UL94V-2

Specifications Panel Thickness

.063 (1.6) inches (mm)

Specifications Remarks Panel Thickness

Panel thickness is for both ends.
