OR-Bolt Steel 12.3mm Body Length 100° Countersunk Head Rivet
OR-Bolt Steel 12.3mm Body Length 100° Countersunk Head Rivet
SKU:ORB-8f15e2
High-strength OR-Bolt Steel Rivet with Zinc Plated Finish. Ideal for heavy-duty applications. Meets industry standards.
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
Initiate Order
OR-Bolt Steel 12.3mm Body Length 100° Countersunk Head Rivet
$59.99
Quantity: 1
Claim Your Seller Account
OR-Bolt Steel 12.3mm Body Length 100° Countersunk Head Rivet
$59.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The OR-Bolt Steel 100° Countersunk Head Rivet by Ornit is a superior fastening solution for heavy-duty applications. Crafted from low carbon steel with a Zinc Plated Chromium VI-Free finish, this rivet ensures exceptional durability and corrosion resistance. With a nominal shear force of 653 kgf and a nominal tensile force of 520 kgf, it meets stringent industry standards for reliability. The 100° countersunk head and precise dimensions make it ideal for a wide range of construction and industrial projects.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Nominal Dimensions Body Length
12.3 mm | 0.484 in
Nominal Dimensions Diameter
4.8 mm | 3/16 in
Nominal Dimensions Drillhole Size
4.9 to 5.1 mm | 0.192 to 0.200 in
Nominal Dimensions Head Diameter
8.6 mm | 0.338 in
Nominal Dimensions Head Thickness
1.80 mm | 0.071 in
Nominal Dimensions Mandrel Diameter
3.0 mm | 0.118 in
Nominal Dimensions Maximum Grip Range
8.4 mm | 0.331 in
Nominal Dimensions Minimum Grip Range
3.2 mm | 0.126 in
Nominal Forces Nominal Shear Force
653 kgf | 1440 lbf
Nominal Forces Nominal Tensile Force
520 kgf | 1146 lbf
Technical Specs Body Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Body Material
Low Carbon Steel
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
4000
Technical Specs Head Style
100 Degree Countersunk
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Medium Carbon Steel
