OR-Bolt Steel 16.6mm Countersunk Head Rivet
OR-Bolt Steel 16.6mm Countersunk Head Rivet
SKU:ORB-667d5e
Premium OR-Bolt Steel 16.6mm Countersunk Head Rivet for durable and reliable fastening solutions.
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
Initiate Order
OR-Bolt Steel 16.6mm Countersunk Head Rivet
$59.99
Quantity: 1
Claim Your Seller Account
OR-Bolt Steel 16.6mm Countersunk Head Rivet
$59.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The OR-Bolt Steel 16.6mm Countersunk Head Rivet by Ornit is a premium fastening solution crafted from low carbon steel with a zinc plated chromium VI-free finish. With a 100-degree countersunk head and a mandrel made of medium carbon steel, this rivet offers exceptional strength and durability. Designed for precision, it features a 6.5mm diameter, 16.6mm body length, and can withstand shear forces up to 1250kgf and tensile forces up to 1000kgf. Meet your fastening needs with reliability and quality that exceeds industry standards.
Product Specifications
Nominal Dimensions Body Length
16.6 mm | 0.654 in
Nominal Dimensions Diameter
6.5 mm | 1/4 in
Nominal Dimensions Drillhole Size
6.62 to 6.9 mm | 0.260 to 0.271 in
Nominal Dimensions Head Diameter
9.8 mm | 0.386 in
Nominal Dimensions Head Thickness
2.00 mm | 0.079 in
Nominal Dimensions Mandrel Diameter
4.0 mm | 0.157 in
Nominal Dimensions Maximum Grip Range
12.1 mm | 0.476 in
Nominal Dimensions Minimum Grip Range
3.2 mm | 0.126 in
Nominal Forces Nominal Shear Force
1250 kgf | 2750 lbf
Nominal Forces Nominal Tensile Force
1000 kgf | 2200 lbf
Technical Specs Body Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Body Material
Low Carbon Steel
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
2000
Technical Specs Head Style
100 Degree Countersunk
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Medium Carbon Steel
