Orlock 6.4mm Steel Countersunk Head Rivet
Orlock 6.4mm Steel Countersunk Head Rivet
SKU:ORL-ced83f
Securely bond seats, frames, hinges, and locking systems with the Orlock 6.4mm Steel Countersunk Head Rivet. Superior strength and vibration resistance for structural applications.
Regular price
$35.99
Regular price
Sale price
$35.99
Unit price
per
Initiate Order
Orlock 6.4mm Steel Countersunk Head Rivet
$35.99
Quantity: 1
Claim Your Seller Account
Orlock 6.4mm Steel Countersunk Head Rivet
$35.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Orlock 6.4mm Steel Countersunk Head Rivet is a top choice for structural applications like securing seats, frames, hinges, and locking systems with exceptional shear and tensile forces. With its double-locking system and low carbon steel body, this rivet offers superior strength and vibration resistance. Featuring zinc-plated chromium finishes and meeting stringent industry standards, it provides a secure and durable fastening solution for various automotive applications.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Applications Automotive Application
Steering Wheel MechanismSafety, and quality products are part of Ornit's DNA. The Orlock⢠with its unique capabilities, and featuring a double-locking system was selected to provide peace of mind to countless drivers worldwide.Automotive - SeatingThe Orlock⢠is a structural fastener, featuring a unique double-locking system that enables the rivet to safely secure the seats.
Nominal Dimensions Body Length
19.5 mm | 0.768 in
Nominal Dimensions Diameter
6.4 mm | 1/4 in
Nominal Dimensions Drillhole Size
6.6 to 6.8 mm | 0.260 to 0.268 in
Nominal Dimensions Head Diameter
10.0 mm | 0.394 in
Nominal Dimensions Head Thickness
2.00 mm | 0.079 in
Nominal Dimensions Mandrel Diameter
4.17 mm | 0.164 in
Nominal Dimensions Maximum Grip Range
13.8 mm | 0.543 in
Nominal Dimensions Minimum Grip Range
11.8 mm | 0.465 in
Nominal Forces Nominal Shear Force
1050 kgf | 2315 lbf
Nominal Forces Nominal Tensile Force
560 kgf | 1235 lbf
Technical Specs Body Finish
Zinc Plated Chromium (Cr) VI Free Passivation
Technical Specs Body Material
Low Carbon Steel
Technical Specs Brands
Orlock⢠| Ornit
Technical Specs Carton Quantity
2000
Technical Specs Head Style
Countersunk
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free Passivation
Technical Specs Mandrel Material
Carbon Steel
