Orlock⢠10.5mm Aluminum X-Large Head Rivet
Orlock⢠10.5mm Aluminum X-Large Head Rivet
SKU:ORL-6f6262
Premium Orlockâ„¢ 10.5mm Aluminum Rivet for secure, vibration-resistant joints in demanding applications.
Regular price
$42.99
Regular price
Sale price
$42.99
Unit price
per
Initiate Order
Orlock⢠10.5mm Aluminum X-Large Head Rivet
$42.99
Quantity: 1
Claim Your Seller Account
Orlock⢠10.5mm Aluminum X-Large Head Rivet
$42.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Orlock⢠10.5mm Aluminum X-Large Head Rivet is a premium structural fastener designed for demanding joint applications. Crafted from high-quality Aluminum Alloy, this rivet offers exceptional shear and tensile forces, ensuring a secure and vibration-resistant joint. With a body length of 10.5mm and an extra-large head style, it provides superior grip range and strength. Trust Orlock⢠for reliable performance and durability in your projects.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Nominal Dimensions Body Length
10.5 mm | 0.413 in
Nominal Dimensions Diameter
6.4 mm | 1/4 in
Nominal Dimensions Drillhole Size
6.6 to 6.8 mm | 0.167 to 0.172 in
Nominal Dimensions Head Diameter
19.0 mm | 0.748 in
Nominal Dimensions Head Thickness
3.0 mm | 0.118 in
Nominal Dimensions Mandrel Diameter
4.17 mm | 0.164 in
Nominal Dimensions Maximum Grip Range
4.8 mm | 0.189 in
Nominal Dimensions Minimum Grip Range
2.8 mm | 0.110 in
Nominal Forces Nominal Shear Force
430 kgf | 946 lbf
Nominal Forces Nominal Tensile Force
350 kgf | 770 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (ALmg 2.5)
Technical Specs Brands
Orlock⢠| Ornit
Technical Specs Carton Quantity
1000
Technical Specs Head Style
Extra Large
Technical Specs Mandrel Finish
Natural
Technical Specs Mandrel Material
Aluminum Alloy (ALmg 5.0 - 6.0) or Equivalent
