Orlock™ 12.5mm Aluminum X-Large Head Rivet

Orlock™ 12.5mm Aluminum X-Large Head Rivet

ORL-5e8970

Secure joints with Orlockâ„¢ 12.5mm Aluminum X-Large Head Rivet. High shear & tensile strength, vibration-resistant, ideal for various applications.

$45.99
$45.99
Sale

Initiate Order

Orlock™ 12.5mm Aluminum X-Large Head Rivet

Orlock™ 12.5mm Aluminum X-Large Head Rivet

$45.99

Quantity: 1

Claim Your Seller Account

Orlock™ 12.5mm Aluminum X-Large Head Rivet

Orlock™ 12.5mm Aluminum X-Large Head Rivet

$45.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The Orlockâ„¢ 12.5mm Aluminum X-Large Head Rivet is a robust structural fastener designed for various joint applications, providing exceptional shear and tensile strength. Its aluminum-alloy construction ensures durability and reliability, creating secure and vibration-resistant joints. With a diameter of 6.4mm and a body length of 12.5mm, this rivet offers a minimum grip range of 4.8mm and a maximum grip range of 6.8mm. Experience high-quality performance and stability with the Orlockâ„¢ rivet, ideal for institutional and government procurement needs.

Ready to Grow Without Cash Flow Constraints?

Get Net 30, 60, or 90 day terms at 0% interest on any purchase

Check Your Eligibility Now
Ready to Grow Without Cash Flow Constraints?

Product Specifications

Nominal Dimensions Body Length
12.5 mm | 0.492 in
Nominal Dimensions Diameter
6.4 mm | 1/4 in
Nominal Dimensions Drillhole Size
6.6 to 6.8 mm | 0.167 to 0.172 in
Nominal Dimensions Head Diameter
19.0 mm | 0.748 in
Nominal Dimensions Head Thickness
3.0 mm | 0.118 in
Nominal Dimensions Mandrel Diameter
4.17 mm | 0.164 in
Nominal Dimensions Maximum Grip Range
6.8 mm | 0.268 in
Nominal Dimensions Minimum Grip Range
4.8 mm | 0.189 in
Nominal Forces Nominal Shear Force
460 kgf | 1012 lbf
Nominal Forces Nominal Tensile Force
350 kgf | 770 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (ALmg 2.5)
Technical Specs Brands
Orlock™ | Ornit
Technical Specs Carton Quantity
1000
Technical Specs Head Style
Extra Large
Technical Specs Mandrel Finish
Natural
Technical Specs Mandrel Material
Aluminum Alloy (ALmg 5.0 - 6.0) or Equivalent
