Orlock™ 12.5mm Stainless Steel Rivet

Orlock™ 12.5mm Stainless Steel Rivet

ORL-8f5d20

Premium 12.5mm stainless steel rivet for industrial use, offering durability and secure joints in harsh environments.

$79.99
$79.99
Sale

Initiate Order

Orlock™ 12.5mm Stainless Steel Rivet

Orlock™ 12.5mm Stainless Steel Rivet

$79.99

Quantity: 1

Claim Your Seller Account

Orlock™ 12.5mm Stainless Steel Rivet

Orlock™ 12.5mm Stainless Steel Rivet

$79.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The Orlock™ 12.5mm Stainless Steel Rivet is a premium fastening solution designed for industrial applications, including trailers and solar frames. Made of high-grade Austenitic Stainless Steel AISI 304, this rivet offers unmatched durability in harsh climate conditions. With a large head for increased strength and a mandrel diameter of 4.17mm, it provides a secure grip range of 4.0mm to 6.5mm. Tested to withstand a nominal shear force of 1480kgf and a nominal tensile force of 850kgf, this rivet ensures superior joint integrity. Trust Orlock™ for quality and reliability in every fastening need.

Ready to Grow Without Cash Flow Constraints?

Get Net 30, 60, or 90 day terms at 0% interest on any purchase

Check Your Eligibility Now
Ready to Grow Without Cash Flow Constraints?

Product Specifications

Applications Renewable Energy Application
Solar FramesThe Orlock™ Stainless Steel is commonly used in a variety of solar applications worldwide. This stainless steel rivet provides a permanent, secure joint in the most severe climate conditions. Also available in 316.
Nominal Dimensions Body Length
12.5 mm | 0.492 in
Nominal Dimensions Diameter
6.4 mm | 1/4 in
Nominal Dimensions Drillhole Size
6.6 to 6.8 mm | 0.259 to 0.267 in
Nominal Dimensions Head Diameter
16.3 mm | 0.642 in
Nominal Dimensions Head Thickness
3.1 mm | 0.122 in
Nominal Dimensions Mandrel Diameter
4.17 mm | 0.164 in
Nominal Dimensions Maximum Grip Range
6.5 mm | 0.256 in
Nominal Dimensions Minimum Grip Range
4.0 mm | 0.157 in
Nominal Forces Nominal Shear Force
1480 kgf | 3256 lbf
Nominal Forces Nominal Tensile Force
850 kgf | 1870 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Austenitic Stainless Steel American Iron and Steel Institute (AISI) 304
Technical Specs Brands
Orlock™ | Ornit
Technical Specs Carton Quantity
2000
Technical Specs Head Style
Large
Technical Specs Mandrel Finish
Natural
Technical Specs Mandrel Material
Austenic Stainless Steel American Iron and Steel Institute (AISI) 304
