Orlockâ„¢ 16.5mm Aluminum X-Large Head Rivet
Orlockâ„¢ 16.5mm Aluminum X-Large Head Rivet
SKU:ORL-e6c444
High-quality 16.5mm aluminum rivet for secure and vibration-resistant joints in structural applications.
Regular price
$45.99
Regular price
Sale price
$45.99
Unit price
per
Initiate Order
Orlockâ„¢ 16.5mm Aluminum X-Large Head Rivet
$45.99
Quantity: 1
Claim Your Seller Account
Orlockâ„¢ 16.5mm Aluminum X-Large Head Rivet
$45.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Orlockâ„¢ 16.5mm Aluminum X-Large Head Rivet is specifically designed for structural applications requiring high shear and tensile forces. Its aluminum alloy construction ensures durability and vibration-resistance, creating secure joints. With a body length of 16.5mm and nominal forces of 500 kgf shear force and 350 kgf tensile force, this rivet guarantees reliable performance in various joint applications.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Nominal Dimensions Body Length
16.5 mm | 0.650 in
Nominal Dimensions Diameter
6.4 mm | 1/4 in
Nominal Dimensions Drillhole Size
6.6 to 6.8 mm | 0.167 to 0.172 in
Nominal Dimensions Head Diameter
19.0 mm | 0.748 in
Nominal Dimensions Head Thickness
3.0 mm | 0.118 in
Nominal Dimensions Mandrel Diameter
4.17 mm | 0.164 in
Nominal Dimensions Maximum Grip Range
10.8 mm | 0.425 in
Nominal Dimensions Minimum Grip Range
8.8 mm | 0.346 in
Nominal Forces Nominal Shear Force
500 kgf | 1100 lbf
Nominal Forces Nominal Tensile Force
350 kgf | 770 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (ALmg 2.5)
Technical Specs Brands
Orlock⢠| Ornit
Technical Specs Carton Quantity
1000
Technical Specs Head Style
Extra Large
Technical Specs Mandrel Finish
Natural
Technical Specs Mandrel Material
Aluminum Alloy (ALmg 5.0 - 6.0) or Equivalent
