Orlock⢠18.5mm Aluminum X-Large Head Rivet
Orlock⢠18.5mm Aluminum X-Large Head Rivet
SKU:ORL-85344b
Orlockâ„¢ 18.5mm Aluminum X-Large Head Rivet provides secure, vibration-resistant joints in various applications.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Orlock⢠18.5mm Aluminum X-Large Head Rivet
$49.99
Quantity: 1
Claim Your Seller Account
Orlock⢠18.5mm Aluminum X-Large Head Rivet
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Orlock⢠18.5mm Aluminum X-Large Head Rivet is a premium structural fastener ideal for a wide range of joint applications. Constructed from high-quality Aluminum Alloy, it offers superior shear and tensile forces, ensuring a secure and vibration-resistant joint. With a body length of 18.5mm, this rivet provides a reliable grip range of 10.8mm to 12.8mm. Trusted by Orlock™ and Ornit, this rivet meets stringent industry standards for durability and performance.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Nominal Dimensions Body Length
18.5 mm | 0.728 in
Nominal Dimensions Diameter
6.4 mm | 1/4 in
Nominal Dimensions Drillhole Size
6.6 to 6.8 mm | 0.167 to 0.172 in
Nominal Dimensions Head Diameter
19.0 mm | 0.748 in
Nominal Dimensions Head Thickness
3.0 mm | 0.118 in
Nominal Dimensions Mandrel Diameter
4.17 mm | 0.164 in
Nominal Dimensions Maximum Grip Range
12.8 mm | 0.504 in
Nominal Dimensions Minimum Grip Range
10.8 mm | 0.425 in
Nominal Forces Nominal Shear Force
500 kgf | 1100 lbf
Nominal Forces Nominal Tensile Force
350 kgf | 770 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (ALmg 2.5)
Technical Specs Brands
Orlock⢠| Ornit
Technical Specs Carton Quantity
1000
Technical Specs Head Style
Extra Large
Technical Specs Mandrel Finish
Natural
Technical Specs Mandrel Material
Aluminum Alloy (ALmg 5.0 - 6.0) or Equivalent
