Orlock⢠22.5mm Aluminum X-Large Head Rivet
Orlock⢠22.5mm Aluminum X-Large Head Rivet
SKU:ORL-224559
Secure structural joints with the Orlock⢠22.5mm Aluminum X-Large Head Rivet, designed for high shear and tensile forces with a reliable grip range.
Regular price
$89.99
Regular price
Sale price
$89.99
Unit price
per
Initiate Order
Orlock⢠22.5mm Aluminum X-Large Head Rivet
$89.99
Quantity: 1
Claim Your Seller Account
Orlock⢠22.5mm Aluminum X-Large Head Rivet
$89.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Orlock⢠22.5mm Aluminum X-Large Head Rivet is a high-strength fastener designed for structural applications in doors and joints. With a dependable grip range of 14.8mm to 16.8mm and nominal shear force of 500 kgf, it ensures a secure and vibration-resistant joint. Crafted from Aluminum Alloy, this rivet meets stringent quality standards for durability and reliability.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Nominal Dimensions Body Length
22.5 mm | 0.886 in
Nominal Dimensions Diameter
6.4 mm | 1/4 in
Nominal Dimensions Drillhole Size
6.6 to 6.8 mm | 0.167 to 0.172 in
Nominal Dimensions Head Diameter
19.0 mm | 0.748 in
Nominal Dimensions Head Thickness
3.0 mm | 0.118 in
Nominal Dimensions Mandrel Diameter
4.17 mm | 0.164 in
Nominal Dimensions Maximum Grip Range
16.8 mm | 0.661 in
Nominal Dimensions Minimum Grip Range
14.8 mm | 0.583 in
Nominal Forces Nominal Shear Force
500 kgf | 1100 lbf
Nominal Forces Nominal Tensile Force
350 kgf | 770 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (ALmg 2.5)
Technical Specs Brands
Orlock⢠| Ornit
Technical Specs Carton Quantity
1000
Technical Specs Head Style
Extra Large
Technical Specs Mandrel Finish
Natural
Technical Specs Mandrel Material
Aluminum Alloy (ALmg 5.0 - 6.0) or Equivalent
