Orlock⢠23.5mm Aluminum Rivet
Orlock⢠23.5mm Aluminum Rivet
SKU:ORL-a83c83
High-quality Orlockâ„¢ 23.5mm Aluminum Rivet for secure, vibration-resistant joints in heavy-duty applications.
Regular price
$45.99
Regular price
Sale price
$45.99
Unit price
per
Initiate Order
Orlock⢠23.5mm Aluminum Rivet
$45.99
Quantity: 1
Claim Your Seller Account
Orlock⢠23.5mm Aluminum Rivet
$45.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Orlock⢠23.5mm Aluminum Rivet is a reliable structural fastener designed for heavy-duty joint applications. Crafted from high-quality Aluminum Alloy, it delivers exceptional shear and tensile forces, ensuring a secure and vibration-resistant joint. With a 100-degree countersunk head, this rivet offers superior fastening performance, ideal for use in doors and various structural projects.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Nominal Dimensions Body Length
23.5 mm | 0.925 in
Nominal Dimensions Diameter
6.4 mm | 1/4 in
Nominal Dimensions Drillhole Size
6.6 to 6.8 mm | 0.259 to 0.267 in
Nominal Dimensions Head Diameter
10.0 mm | 0.394 in
Nominal Dimensions Head Thickness
2.00 mm | 0.79 in
Nominal Dimensions Mandrel Diameter
4.17 mm | 0.164 in
Nominal Dimensions Maximum Grip Range
17.8 mm | 0.701 in
Nominal Dimensions Minimum Grip Range
15.8 mm | 0.622 in
Nominal Forces Nominal Shear Force
500 kgf | 1100 lbf
Nominal Forces Nominal Tensile Force
300 kgf | 660 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (ALmg 2.5)
Technical Specs Brands
Orlock⢠| Ornit
Technical Specs Carton Quantity
2000
Technical Specs Head Style
Countersunk
Technical Specs Mandrel Finish
Natural
Technical Specs Mandrel Material
Aluminum Alloy 7075 or Equivalent
