Orlock™ 6.4mm Stainless Steel Protruding Head Rivet

Orlock™ 6.4mm Stainless Steel Protruding Head Rivet

ORL-d6f8a5

Premium stainless steel rivet for trailers & solar applications, offers exceptional strength & durability in harsh climates.

$49.99
$49.99
Sale

Initiate Order

Orlock™ 6.4mm Stainless Steel Protruding Head Rivet

Orlock™ 6.4mm Stainless Steel Protruding Head Rivet

$49.99

Quantity: 1

Claim Your Seller Account

Orlock™ 6.4mm Stainless Steel Protruding Head Rivet

Orlock™ 6.4mm Stainless Steel Protruding Head Rivet

$49.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The Orlockâ„¢ 6.4mm Stainless Steel Protruding Head Rivet is a premium fastening solution ideal for trailer manufacturing and solar applications. Made of AISI 304 stainless steel, it ensures a permanent, secure joint in harsh climate conditions. With a shear force of 1440kgf and a tensile force of 850kgf, this rivet offers exceptional strength and reliability. The 10.5mm body length and 6.4mm diameter cater to a wide range of grip requirements, making it versatile and robust for various industrial needs.

Ready to Grow Without Cash Flow Constraints?

Get Net 30, 60, or 90 day terms at 0% interest on any purchase

Check Your Eligibility Now
Ready to Grow Without Cash Flow Constraints?

Product Specifications

Applications Renewable Energy Application
Solar FramesThe Orlock™ Stainless Steel is commonly used in a variety of solar applications worldwide. This stainless steel rivet provides a permanent, secure joint in the most severe climate conditions. Also available in 316.
Nominal Dimensions Body Length
10.5 mm | 0.413 in
Nominal Dimensions Diameter
6.4 mm | 1/4 in
Nominal Dimensions Drillhole Size
6.6 to 6.7 mm | 0.260 to 0.264 in
Nominal Dimensions Head Diameter
13.0 mm | 0.512 in
Nominal Dimensions Head Thickness
3.0 mm | 0.118 in
Nominal Dimensions Mandrel Diameter
4.17 mm | 0.164 in
Nominal Dimensions Maximum Grip Range
4.5 mm | 0.177 in
Nominal Dimensions Minimum Grip Range
2.0 mm | 0.079 in
Nominal Forces Nominal Shear Force
1440 kgf | 3175 lbf
Nominal Forces Nominal Tensile Force
850 kgf | 1874 lbf
Note Note
Can be Produced with Austenitic Stainless Steel A4 - AISI 316
Technical Specs Body Finish
Natural
Technical Specs Body Material
Austenitic Stainless Steel American Iron and Steel Institute (AISI) 304
Technical Specs Brands
Orlock™ | Ornit
Technical Specs Carton Quantity
2000
Technical Specs Head Style
Protruding
Technical Specs Mandrel Finish
Natural
Technical Specs Mandrel Material
Austenitic Stainless Steel 304
