Orlock™ 6.4mm Steel Countersunk Head Rivet

Orlock™ 6.4mm Steel Countersunk Head Rivet

ORL-c82ae6

Premium 6.4mm Steel Rivet with Double-Locking System for Secure Joints and Vibration Resistance

$49.99
$49.99
Sale

Initiate Order

Orlock™ 6.4mm Steel Countersunk Head Rivet

Orlock™ 6.4mm Steel Countersunk Head Rivet

$49.99

Quantity: 1

Claim Your Seller Account

Orlock™ 6.4mm Steel Countersunk Head Rivet

Orlock™ 6.4mm Steel Countersunk Head Rivet

$49.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The Orlock™ 6.4mm Steel Countersunk Head Rivet is a premium structural fastener designed for high shear and tensile forces. Its double-locking system ensures secure and vibration-resistant joints, making it ideal for various applications like seating, frames, hinges, and locking systems. With low carbon steel body, zinc-plated chromium VI free passivation finish, and exceptional grip range, this rivet offers reliability and strength for automotive and industrial use.

Ready to Grow Without Cash Flow Constraints?

Get Net 30, 60, or 90 day terms at 0% interest on any purchase

Check Your Eligibility Now
Ready to Grow Without Cash Flow Constraints?

Product Specifications

Applications Automotive Application
Steering Wheel MechanismSafety, and quality products are part of Ornit's DNA. The Orlock™ with its unique capabilities, and featuring a double-locking system was selected to provide peace of mind to countless drivers worldwide.SeatingThe Orlock™ is a structural fastener, featuring a unique double-locking system that enables the rivet to safely secure the seats.
Nominal Dimensions Body Length
11.5 mm | 0.453 in
Nominal Dimensions Diameter
6.4 mm | 1/4 in
Nominal Dimensions Drillhole Size
6.6 to 6.8 mm | 0.260 to 0.268 in
Nominal Dimensions Head Diameter
10.0 mm | 0.394 in
Nominal Dimensions Head Thickness
2.00 mm | 0.079 in
Nominal Dimensions Mandrel Diameter
4.17 mm | 0.164 in
Nominal Dimensions Maximum Grip Range
5.8 mm | 0.228 in
Nominal Dimensions Minimum Grip Range
3.8 mm | 0.150 in
Nominal Forces Nominal Shear Force
550 kgf | 1213 lbf
Nominal Forces Nominal Tensile Force
560 kgf | 1235 lbf
Technical Specs Body Finish
Zinc Plated Chromium (Cr) VI Free Passivation
Technical Specs Body Material
Low Carbon Steel
Technical Specs Brands
Orlock™ | Ornit
Technical Specs Carton Quantity
2000
Technical Specs Head Style
Countersunk
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free Passivation
Technical Specs Mandrel Material
Carbon Steel
